Client Status (Block 9251) Table - ProSoft Technology ProTalk PTQ-104C User Manual

49TPTQ-104C ♦ 48TQuantum Platform
47TIEC 60870-5-104 Client
Word Offset in Block
17
18
19
20
21
22 to 23
24
25
26
27
28
29
30
9.5

Client Status (Block 9251) Table

This section contains the block structure of the PTQ-104C module's Client status
data from Block 9251.
Word Offset
in Block
0
1
ProSoft Technology, Inc.
March 4, 2013
Data Field(s)
Current Command
Command Busy
Flag
Command Count
Command Delay
Command Queue
Command Queue
Count
Online Status
SNTP Valid
NTP Request
NTP Response
SNTP Computation Number of times SNTP time computed
SNTP Set
NTP Timeout
Data Field(s) Description
Block Identification Code 9251
Block ID Code
Active Active status of client
0 = Not active
1 = Waiting on StartDT connection
2 = Online (StartDT connection received)
Description
This word contains the index of the current
command being executed in the command list.
This word is set to zero if no command is currently
being executed and waiting on a response. If the
word is set to 1, a command is currently executing.
This word contains the count of the number of
commands configured for the module.
This word contains the command delay counter
preset. There is a fixed delay between each
command to permit the module to perform other
operations.
This word is set to zero if the command executing
is from the command list. If the executing command
is from the command queue, the word will be set to
1.
This word contains the number of active
commands in the command queue for the module.
Up to 100 commands can be buffered in this
queue. These commands are transferred from the
processor to the module using special command
blocks.
This double word value contains a bit for each of
the 32 potential sessions in the module. If the bit is
set for a session in the double word, the station is
online. If the bit is clear, the station is offline. Use
this value to determine if commands sent from the
processor will have a chance of succeeding.
NTP time is valid (0=No, 1=Yes)
Number of requests to NTP server
Number of responses from NTP server
Number of times SNTP time set
Number of NTP response timeouts
Reference
12TUser Manual
Page 117 of 136
