Gateway field
The Gateway field identifies the address of the gateway to the mail server to be
used if the switcher and the mail server are not on the same subnet.
Valid IP addresses consist of four 1-, 2-, or 3-digit octets separated by dots (periods).
Each octet can be numbered from 000 through 255. Leading zeroes, up to 3 digits
total per octet, are optional. Values of 256 and above are invalid.

Subnet Mask field

The Subnet Mask field is used to determine whether the switcher is on the same
subnet as the controlling PC or the mail server when you are subnetting. For more
information, see "Subnetting — A Primer", in Appendix A, "Ethernet Connection".

Mail Server IP Address field

The Mail Server IP Address field displays the IP address of the mail server that
handles the e-mail for the facility in which the switcher is installed.
Valid IP addresses consist of four 1-, 2-, or 3-digit numeric octets separated by dots
(periods). Each field can be numbered from 000 through 255. Leading zeroes, up to
3 digits total per field, are optional. Values of 256 and above are invalid.

Mail Server User Name field

The User Name field contains the name used as the "from" information when the
switcher e-mails notification of its failed or repaired status. This descriptor can be
changed to any valid name, up to 12 alphanumeric characters.
N The following characters are invalid in the User Name field:
{space} + ~ , @ = ' [ ] { } < > ' " ; : | \ and ?.
Mail Server Domain Name field
The Mail Server Domain Name field displays the domain name that the switcher
uses to log on to the e-mail server. Standard domain conventions (such as
nnnnn@xxx.com) apply.
N The following characters are invalid in a domain name:
{space} + ~ , = ' [ ] { } < > ' " ; : | \ and ?. The @ character is
acceptable only as the lead-in to the domain name (such as @folklore.net).

Mail Server User Password field

The Mail Server User Password field displays the password required to log on to
the mail server. Passwords are case sensitive and are limited to 12 lowercase and
lowercase alphanumeric characters.
While you are logged on as a user, this field is masked with asterisks (****) as a
security measure.
N The following characters are invalid in passwords:
{space} + ~ , @ = ' [ ] { } < > ' " ; : | \ and ?.
ISS 506 Integration Seamless Switcher • Switcher Software 5-15
