Installation Guide
Optional Input and Output Board Installation
ce-info@camboard.de
ISS 506 I/O Boards
68-1333-01 Rev. A
01 07

Advertisement

loading
Need help?

Need help?

Do you have a question about the ISS 506 and is the answer not in the manual?

Questions and answers

Related Manuals for Extron electronics ISS 506

Summary of Contents for Extron electronics ISS 506

  • Page 1 PM Industrial Bldg., Singapore 368363 Chiyoda-ku, Tokyo 102-0082 01 07 800.633.9876 714.491.1500 +800.3987.6673 +31.33.453.4040 +800.7339.8766 +65.6383.4400 Japan FAX 714.491.1517 FAX +31.33.453.4050 FAX +65.6383.4664 +81.3.3511.7655 FAX +81.3.3511.7656 www.extron.com www.camboard.de Tel. 07131 911201 ce-info@camboard.de © 2007 Extron Electronics. All rights reserved. Fax 07131 911203...
  • Page 2 Reparaciones/mantenimiento • Solicitar siempre los servicios técnicos de personal use. In no event will Extron Electronics be liable for direct, indirect, or consequential califi cado. En el interior no hay partes a las que el usuario deba acceder. Para evitar riesgo de electrocución, no intentar personalmente la reparación/mantenimiento...
  • Page 3 im Vertrieb von CAMBOARD Electronics www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 4: Installation

    Installation im Vertrieb von CAMBOARD Electronics The ISS 506 can be modified to install or remove optional boards that change the input and/or output formats that the switcher can process. The following optional I/O boards are available: SDI/HD-SDI input •...
  • Page 5 T IT /T IN In t r a t io n I S S le s w it Figure 1 — Removing the ISS cover www.camboard.de Tel. 07131 911201 ce-info@camboard.de ISS 506 Optional I/O board • Installation Fax 07131 911203...
  • Page 6 Install an optional SDI/HD-SDI input board in the ISS as follows: Changes to electronic components must be performed by authorized service personnel only. To prevent electric shock, always unplug the ISS from the AC power source before opening the enclosure. Open the switcher. See “Opening the Switcher” on page 1. Do not touch any switches or other electronic components inside the ISS. Doing so could damage the ISS. Electrostatic discharge (ESD) can damage IC chips even though you cannot feel it. You must be electrically grounded before proceeding with any electronic component replacement. A grounding wrist strap is recommended. www.camboard.de Tel. 07131 911201 ce-info@camboard.de ISS 506 Optional I/O board • Installation Fax 07131 911203...
  • Page 7 Figure 2 — SDI/HD-SDI input board installation location From the inside of the switcher, pop the cover out of the rear panel connector port ( www.camboard.de Tel. 07131 911201 ce-info@camboard.de ISS 506 Optional I/O board • Installation Fax 07131 911203...
  • Page 8 See figure 3, above. Align the connectors on the main board and board ( ). Gently apply pressure to carefully mate the input board with the main board. www.camboard.de Tel. 07131 911201 ce-info@camboard.de ISS 506 Optional I/O board • Installation Fax 07131 911203...
  • Page 9 See figure 4. Secure the board to the standoffs on the main board with the three included screws ( Figure 4 — Secure the input board to the standoffs www.camboard.de Tel. 07131 911201 ce-info@camboard.de ISS 506 Optional I/O board • Installation Fax 07131 911203...
  • Page 10 Extron recommends that you send the unit to Extron for service and updates. Install an optional output board in the ISS as follows: Changes to electronic components must be performed by authorized service personnel only. To prevent electric shock, always unplug the ISS from the AC power source before opening the enclosure. www.camboard.de Tel. 07131 911201 ce-info@camboard.de ISS 506 Optional I/O board • Installation Fax 07131 911203...
  • Page 11 On the main board (figure 7), locate connectors J1, J2A, and J2B ( ); the standoff ( ); and the rear panel connector port ( www.camboard.de Tel. 07131 911201 ce-info@camboard.de ISS 506 Optional I/O board • Installation Fax 07131 911203...
  • Page 12 Installation, cont’d im Vertrieb von CAMBOARD Electronics Figure 7 — Output board installation location www.camboard.de Tel. 07131 911201 ce-info@camboard.de ISS 506 Optional I/O board • Installation Fax 07131 911203...
  • Page 13 Align one or both connector extension(s) with J1 and J2A/J2B on the main board ( ). Gently apply pressure to carefully mate the extension(s) with the main board (figure 8). N To make installation of the board easier, angle the extensions slightly away from the rear of the ISS as shown. Figure 8 — Connector extensions www.camboard.de Tel. 07131 911201 ce-info@camboard.de ISS 506 Optional I/O board • Installation Fax 07131 911203...
  • Page 14 See figure 9. Align the connector(s) on the board with those on the extension(s) ( ). Gently apply pressure to carefully mate the output board with the main board. Figure 9 — Output board installation www.camboard.de Tel. 07131 911201 ce-info@camboard.de ISS 506 Optional I/O board • Installation Fax 07131 911203...
  • Page 15 Figure 10 — Output board installation Ensure that each contact on the connector extension(s) is properly mated with the output board, and not shifted to the front or rear. If the board’s rear panel is not flush with the ISS’s rear panel, the board is probably not properly mated. See figure 11. Secure the output board to the standoff on the main board with the included screw ( www.camboard.de Tel. 07131 911201 ce-info@camboard.de ISS 506 Optional I/O board • Installation Fax 07131 911203...
  • Page 16 Installation, cont’d im Vertrieb von CAMBOARD Electronics Figure 11 — Secure the output board to the standoff www.camboard.de Tel. 07131 911201 ce-info@camboard.de ISS 506 Optional I/O board • Installation Fax 07131 911203...

  • Page 17: Closing The Switcher

    Fasten it with the screws that were removed in “Opening the Switcher“, on page 1, step 3. Rack mount the switcher, if desired, and reconnect all cables. www.camboard.de Tel. 07131 911201 ce-info@camboard.de ISS 506 Optional I/O board • Installation Fax 07131 911203...
