CONTAINERIZED KITCHEN (CK)
INTRODUCTION

MALFUNCTION/SYMPTOM INDEX

The malfunction/symptom index (WP 0009 00) is a quick reference for finding troubleshooting
procedures. Associated with each symptom name is a work package sequence number
representing the starting point in a troubleshooting sequence. As the troubleshooting activity
progresses through to the conclusion of a sequence, a reference is made to the next logical
troubleshooting sequence by work package sequence number or by referring to the
malfunction/symptom index to locate the next failure symptom work package. This type of
activity continues until successful fault isolation is achieved.
TROUBLESHOOTING PROCEDURES
The troubleshooting work packages contain tables listing the malfunctions, checks or
inspections, and corrective actions required to return the equipment to normal operation.
Perform the steps in the order they appear in the tables.
Each work package is headed by an initial setup. This setup outlines what is needed as well as
the conditions that must be met before starting the task. DO NOT START A TASK UNTIL:
•
You understand the task.
•
You understand what you are to do.
•
You understand what is needed to do the work.
•
You have the things you need.
This manual cannot list all malfunctions that may occur, or all tests, inspections and corrective
actions. If a malfunction is not listed or is not corrected by listed corrective actions, notify unit
maintenance.
GENERAL INFORMATION
When troubleshooting the electrical system with power connected, place all switches and circuit
breakers in the OFF position.
If any circuit breaker trips after it has been reset, notify unit maintenance.
TM 10-7360-226-13&P
0008 00-1/2 Blank
0008 00
