CONTAINERIZED KITCHEN (CK)
DESCRIPTION OF OPERATOR CONTROLS AND INDICATORS
Main Control Panel
The Main Control Panel (MCP), Figure 3, is located in the food preparation area, on the wall to
the right of the personnel access door. It houses the controls and indicators for selecting,
connecting, and disconnecting electrical power, and for operating the CK's interior lights. These
consist of the following:
•
EMERGENCY STOP (E-Stop) pushbutton: Disconnects all electrical power from the
CK in the event of an emergency. Shuts down the generator if it is running.
•
Power OFF pushbutton: During normal operation, disconnects all electrical power
from the CK. Does not shut down the generator.
•
EXTERNAL POWER ON pushbutton: Connects external power to supply the CK.
Lights green when external power is connected. Operates only if external power is
available.
•
GENERATOR POWER ON pushbutton: Connects generator power to supply the
CK. Lights green when generator power is connected. Operates only if generator
power is available.
•
EXTERNAL POWER AVAILABLE indicator (amber): Lit when external power is
available.
•
GENERATOR POWER AVAILABLE indicator (amber): Lit when generator power is
available.
•
INTERIOR LIGHTING switch: Turns the interior lights ON and OFF.
•
LIGHTING MODE switch: Selects NORMAL or BLACKOUT mode.
•
EMERGENCY LIGHT switch: Connects (ON) and disconnects (OFF) the internal
battery in the emergency lighting fixture. Whenever the kitchen is energized, the
switch should be ON so the battery will charge. If the kitchen is de-energized, the
switch should be turned OFF as soon as emergency lighting is no longer needed.
