CONTAINERIZED KITCHEN (CK)
DESCRIPTION OF OPERATOR CONTROLS AND INDICATORS
MBU Converter
The MBU converter, Figure 5, is mounted on the wall in the mechanical room, and has the
following controls and indicators:
•
MAIN POWER switch (1): Turns the converter ON and OFF.
•
Output A (2): 24 VDC output connector #1.
•
Output B (3): 24 VDC output connector #2.
•
Indicator light (4): Lit when power is on.
TM 10-7360-226-13&P
MBU
POWER
ON
OFF
Figure 4. MBU Power Switch.
0005 00-5
0005 00
