CONTAINERIZED KITCHEN (CK)

OPERATION UNDER USUAL CONDITIONS

INITIAL SETUP:
CK packed out
Maintenance Level
Operator/Crew
GENERAL
When the CK arrives at the deployment site, all equipment necessary for setup and operation is
packed inside the container. This work package provides step-by-step instructions for siting,
leveling and expanding the container, erecting the shelter, and configuring the CK for meal
preparation under usual operating conditions. Except as noted, all steps must be performed in
the order given.
SITE REQUIREMENTS
1. If the CK is mounted on a trailer, the selected site must have a minimum of 50 ft x 30 ft of
level, open space to provide maneuvering room for the tow vehicle and trailer.
2. The site must be level to a maximum elevation difference of 6 inches in 10 feet. If in doubt,
consult the Operations Supervisor or Unit Commander.
3. The terrain must be firm, well drained, and relatively free of surface rocks and stones. If the
soil at the site is not dry and well packed, dunnage or other support materials must be
placed under the jack base plates to prevent them from sinking.
4. The slope of the terrain must not exceed 18 inches over the projected floor area of the
expanded shelter (approximately 20 ft x 22 ft).
Supervisor or Unit Commander.
5. If there are prevailing winds, the CK should be oriented so that exhaust gases from the
onboard generator will not blow into the shelter or be drawn into the ventilation system.
6. If external electrical power will be used, the CK must be positioned within reach of the
available power cable. If possible, the cable should be routed away from personnel and
vehicular traffic paths. If the cable must be routed across a road or other potential vehicle
path, it must be protected from damage.
7. Depending upon the makeup of the operating crew, a step aid may be required to perform
some setup procedures.
ASSEMBLY AND PREPARATION FOR USE
1. With the tow vehicle, position the trailer in the desired location.
Requirements", earlier.
2. Refer to TM 9-2330-328-14&P for procedures to retrieve, install and operate the trailer
leveling jacks, and to disconnect the trailer from the tow vehicle.
3. Disconnect the tow vehicle and move it out of the way before leveling the trailer.
TM 10-7360-226-13&P
0006 00-1
Personnel Required
Four (plus one supervisor)
If in doubt, consult the Operations
0006 00
Refer to "Site
