CONTAINERIZED KITCHEN (CK)
MAINTENANCE ALLOCATION CHART (MAC)
(1) (2)
GROUP COMPONENT/
NO. ASSEMBLY
03 COOK CENTER
0301 GRIDDLE
ASSEMBLY
0302 STEAM TABLE &
ADAPTER TOP
0303 COOK POT
CRADLE
ADAPTER
0304 COOK POT
CRADLE
ASSEMBLY
030401 BASE RACK
030402 BURNER RACK
030403 COOK POT
CRADLE
0305 FUEL LINE
ASSEMBLY
0306 24 VDC POWER
CABLE
ASSEMBLY
0307 BASE ASSEMBLY
04 EXHAUST HOOD
05 DUAL OVEN
ASSEMBLY
0501 OVENS
0502 OVEN FAN
ASSEMBLY
TM 10-7360-226-13&P
Table 1. MAC for CK – Continued.
(3)
MAINTENANCE LEVEL
MAINTENANCE
UNIT
FUNCTION
C O
INSPECT 0.1
REPAIR 0.4
INSPECT 0.1
REPAIR 0.5
INSPECT 0.1
REPAIR 0.3
INSPECT 0.1
REPAIR 0.2
INSPECT 0.1
REPAIR 0.2
INSPECT 0.1
REPAIR 0.2
INSPECT 0.1
REPLACE 0.5
INSPECT 0.1
REPAIR 0.3
REPLACE 0.5
INSPECT 0.2
REPAIR 0.4
INSPECT 0.1
REPAIR 0.5
INSPECT 0.1
REPAIR 0.3
INSPECT 0.1
REPAIR 0.2
0032 00-6
(4)
TOOLS AND
EQUIPMENT
DS GS DEPOT
REFERENCE CODE
F H D
0.6
1.0
0.5
0.5
0.5
0.5
1.2
0.5
0.5
0.3
0032 00
(5) (6)
REMARKS
CODE
A, V
A, V
A, U, V
A, V
A, V
A, U, V
A, T
C
A, H
A, U, V
A, U, V
A, E, U
