CONTAINERIZED KITCHEN (CK)
OPERATION UNDER USUAL CONDITIONS
Do not attempt to connect an energized cable to the Power Entrance
Panel.
2. Ensure that external power is turned off at its source, then connect the cable at the Power
Entrance Panel.
3. Connect the opposite end of the cable to the source, if not already connected, and energize
the source. Verify that the amber EXTERNAL POWER AVAILABLE indicator is lit.
4. If the GENERATOR POWER ON indicator is lit, press the System Power OFF pushbutton
and verify that the light goes out. This ensures that the kitchen is de-energized before
applying external power.
5. If it is running, shut down the generator as described in TM 9-6115-642-10.
6. Disconnect the ground cable from the ground terminal on the Power Entrance Panel.
7. Press the EXTERNAL POWER ON pushbutton and verify that it lights green.
8. Turn the EMERGENCY LIGHT switch to ON to charge the emergency lighting battery. If
desired, turn on the lights using the INTERIOR LIGHTS switch.
9. Turn on the ECU and the cook center ventilation fans as desired. Their controls are located
to the right of the spice rack. Position the ECU control switch to the desired operating
mode.
Appliance and Equipment Relocation
The CK is shipped with most of its appliances and associated equipment tied down so that they
are not damaged during shipment. These items must be relocated to their designated operating
positions as described below. The refrigerators should have already been moved into the
serving wing to allow access for erecting the shelter on the food preparation wing.
Before moving items with casters, ensure that the casters are unlocked.
After unstrapping and positioning the various items, store the straps on the hanger bars on the
food preparation side wall of the mechanical room.
As the electrical appliances and lights are positioned in the following steps, they are plugged
into designated outlets in the raceway located in the ceiling of the shelter core. These outlets
are shown in Figure 13. If necessary, appliances and other items may be temporarily moved to
reach the plugs.
TM 10-7360-226-13&P
WARNING
0006 00-17
0006 00
