CONTAINERIZED KITCHEN (CK)
UNIT MAINTENANCE PROCEDURES
Caster: See Figure 2. To replace a front caster, unsnap and remove the grille at the bottom of
the refrigerator, then remove the drip pan. To replace a rear caster, remove the access cover at
the bottom rear of the unit.
Two people are required to lay the refrigerator on its back.
Place the refrigerator on its back on the kitchen floor. Check the faulty caster for free rotation.
Remove the hex nut and the caster. Install the new caster and hex nut. Place the refrigerator in
its upright position. As applicable, reinstall the drip pan, grille, and access cover. If possible,
allow the refrigerator to remain in its upright position for an hour before applying power.
MOUNTING
HARDWARE
END OF WORK PACKAGE
TM 10-7360-226-13&P
WARNING
CASTER
Figure 2. Swivel Caster Replacement.
0022 00-3/4 Blank
