TM 10-7360-226-13&P
CONTAINERIZED KITCHEN (CK) 0023 00
UNIT MAINTENANCE PROCEDURES
REPLACE
Caster: See Figure 1. Drain the Tray Pack Heater. Support the Tray Pack Heater with a
wooden block in the vicinity of the caster while the caster is being replaced. Remove the four
bolts and the damaged caster. Install the new caster and mounting hardware.
Drain Valve: See Figure 1. Drain any liquid from the Tray Pack Heater. Remove the drain
valve and replace using pipe joint compound (WP 0051 00, Table 1, Item 3) as required.
Heater Fan: Disconnect the fan assembly power cord. Remove and retain the fan assembly
mounting hardware. Install the replacement fan using the retained hardware.
Lifting Handles: Refer any damage to the lifting handles to Direct Support maintenance.
MBU: Refer to TM 10-7310-282-13&P for MBU repair procedures.
VENT HOSE
DRAIN VALVE
FUEL LINE
CASTER
MBU
Figure 1. Tray Pack Heater Components.
END OF WORK PACKAGE
0023 00-2
