CONTAINERIZED KITCHEN (CK)
OPERATION UNDER USUAL CONDITIONS
4. Connect the other end of the grounding cable to the grounding terminal on the Power
Entrance Panel. Ensure that the connection is tight.
Energizing the CK from the Onboard Generator
The following procedures should be followed to properly and safely supply power to the kitchen
from the generator.
appliances and utilities all at once, it is not recommended that all loads be turned on at the
same time. The following procedures allow the kitchen to be brought on line safely and
effectively. Except as noted, the applicable controls and indicators are located on the Main
Control Panel, shown in Figure 12.
If appliances have been moved into position before energizing the
onboard generator, ensure that the switches for the water pump and
water heater are left OFF until the water system and water heater are
filled. Energizing these components without water in them will result in
equipment damage. Also turn off the lights, exhaust fans, and oven fan.
The refrigerators may be plugged in and turned on, and the
Environmental Control Unit (ECU) has a built in time delay and may be
left on.
1. From the generator control panel, start the generator and close its output contactor (AC
Circuit Interrupter) in accordance with the procedures in TM 9-6115-642-10.
2. Verify that the amber GENERATOR POWER AVAILABLE indicator is lit.
3. If the EXTERNAL POWER ON indicator is lit, press the black System Power OFF button
and verify that the light goes out. This ensures that the kitchen is de-energized before
applying generator power.
Before applying generator power, ensure that the kitchen is properly
grounded as described in "Grounding", above.
4. Press the GENERATOR POWER ON pushbutton and verify that it lights green.
TM 10-7360-226-13&P
While the generator is capable of taking the full load of the kitchen
CAUTION
CAUTION
0006 00-15
0006 00
