CONTAINERIZED KITCHEN (CK)
OPERATION UNDER USUAL CONDITIONS
When raising or lowering the wings, one member of the crew must act as
a spotter to ensure that all personnel stay clear.
8. Winch up the wing using the right winch. When the wing is approximately halfway up, stop
winching. Push in on the fabric at each end of the wing so it will properly fold up as the wing
is closed.
9. Continue winching up the wing. When it is nearly closed, climb onto the container and
attach the orange safety strap. After the strap is attached, unlock and rotate the four cam-
locks on the side of the wing 90
10. Continue winching up the wing until it is almost closed and the winch becomes hard to turn.
The spotter can advise the person operating the winch when the wing is almost closed.
11. Partially engage the four cam-locks by rotating their handles approximately 45
locked position. Crank the wing closed a few more turns, then completely engage and lock
the cam-locks.
12. Return the jack/winch handle to its storage location on the side of the rifle rack. Strap it in
place with its handle end up.
13. Pack the three pairs of stair railings upside down just inside the personnel door. Strap the
railings in place on both sides of the door using two short rubber straps.
14. On the Main Control Panel, turn the INTERIOR LIGHTING and EMERGENCY LIGHT
switches OFF.
15. Close and latch the personnel door.
Jack Removal
If they were used, remove the corner jacks and screw jacks as follows.
1. Lower the corner jacks until the end of the container is resting on the ground. Remove the
jacks.
2. Install the corner jacks at the opposite end of the container. Raise the end of the container
just until the weight is off of the screw jacks. Remove the screw jacks.
3. Lower the corner jacks until the end of the container is resting on the ground. Remove the
jacks.
Mechanical Room Packout
To prevent personal injury, notify personnel inside the CK before
removing the platform from in front of the personnel door.
1. If the CK is mounted on a trailer, install the platform at the mechanical room doors. Hook
the platform into the bracket on the container and support the other side using two wing
jacks.
TM 10-7360-226-13&P
WARNING
o
so their handles are pointing straight outward.
WARNING
0006 00-34
0006 00
o
toward their
