CONTAINERIZED KITCHEN (CK)
GROUP 05 DUAL OVEN ASSEMBLY REPAIR PARTS
(1) (2) (3)
ITEM SMR
NO. CODE NSN
1 PAOZZ
2 PAOZZ
3 PAOZZ
4 PAOZZ
5 PAOZZ
6 PAOZZ 4730-00-795-6959
7 PAOZZ 5340-01-144-2649
TM 10-7360-226-13&P
(4) (5)
PART
CAGEC NUMBER
0U5N7 47012152-5
0U5N7 47012152-2
0U5N7 47012152-4
0U5N7 47012153-2
7S077 44X
73992 B2-H16
7S077 P-SDC-2-HK
0037 00-7
(6)
DESCRIPTION AND USABLE ON
CODE (UOC)
GROUP 05 DUAL OVEN ASSEMBLY
FIGURE 13 FUEL LINE ASSEMBLY
HOSE ASSEMBLY, FUEL, MALE ELBOW TO
FEMALE, 114" .........................................................1
HOSE ASSEMBLY, FUEL, MALE ELBOW TO
FEMALE, 36" ...........................................................2
HOSE ASSEMBLY, FUEL, MALE ELBOW TO
FEMALE, 84" .......................................................... 1
HOSE ASSEMBLY, FUEL, FEMALE SWIVEL
BOTH ENDS, 27-1/4".............................................. 1
TEE, UNION, BRASS ............................................. 2
COUPLING, FEMALE............................................. 4
PLUG, DUST .......................................................... 2
END OF FIGURE
0037 00
(7)
QTY
