CONTAINERIZED KITCHEN (CK)
OPERATION UNDER USUAL CONDITIONS
5. Turn the EMERGENCY LIGHT switch to ON to charge the emergency lighting battery. If
desired, turn on the lights using the INTERIOR LIGHTING switch.
6. Turn on the ECU and the cook center ventilation fans as desired. Their controls are located
next to the spice rack. Position the ECU control switch to the desired operating mode.
Energizing the CK from External Power
The CK can be operated from an external 120/208VAC, 60-amp, 3-phase power source. A
cable from the external source must be provided.
receptacle on the Power Entrance Panel located on the left wall in the mechanical room.
If appliances have been moved into position before energizing external
power, ensure that the switches for the water pump and water heater are
left OFF until the water system and water heater are filled. Energizing
these items without water in them will result in equipment damage.
1. Turn off the water pump and water heater at the appliance control box unless the water
system is charged and the water heater is full.
TM 10-7360-226-13&P
EXTERNAL
POWER
AVAILABLE E-STOP
SYSTEM PO WER SELECTION
EXTERNAL
OFF
POWER O N
ON
OFF
INTERIOR
EMERGENCY
LIGHTING
LIGHT
Figure 12. Main Control Panel.
CAUTION
0006 00-16
GENERATOR
POWER
AVAILABLE
GENERATOR
POWER O N
ON NORMAL
OFF BLACKO UT
LIGHTING
MODE
The cable should be attached to the
0006 00
