CONTAINERIZED KITCHEN (CK)
DESCRIPTION OF OPERATOR CONTROLS AND INDICATORS
MODERN BURNER UNIT (MBU)
MBU Power Switch
The MBU POWER switch, Figure 4, is located on the wall in the food preparation area, next to
the spice rack. It is an ON/OFF toggle switch that controls the 110 VAC receptacle in the
mechanical room that the MBU converter plugs into. Placing the switch in OFF shuts down all
operating MBUs.
TM 10-7360-226-13&P
EXTERNAL
POWER
AVAILABLE
E-STOP
SYSTEM PO WER SELECTION
EXTERNAL OFF
POWER O N
ON
OFF
INTERIOR
EMERGENCY
LIGHTING
LIGHT
Figure 3. Main Control Panel.
0005 00-4
GENERATOR
POWER
AVAILABLE
GENERATOR
POWER O N
ON NORMAL
OFF BLACKO UT
LIGHTING
MODE
0005 00
