TM 10-7360-226-13&P
CONTAINERIZED KITCHEN (CK) 0017 00
UNIT MAINTENANCE PROCEDURES
To install a new cable, feed the end of the cable opposite the ferrule through the hole from
inside the Mechanical Room. Avoid twisting and kinking the cable. Feed the end of the cable
through the tube at the edge of the side floor. With one person pulling the cable through the
tube and another person guiding the cable, continue routing the cable through the side floor
tube until all excess cable is through the tube. Route the cable through the passage over the
personnel door, over the pulley and down to the winch. Wind the cable onto the winch drum for
a full turn and secure the cable to the drum using retained hardware. With one person guiding
the cable from outside the shelter, another person winds the cable evenly onto the winch.
Inspect the cable carefully and avoid twists or kinks as it winds onto the drum. Inspect the cable
all the way along its path and make sure it is tight at the ferrule end in the Mechanical Room.
Replace the black plastic plug.
Winch Replacement: With the side floor down and supported by wing jacks, or with the side
floor up and the cam-locks locked, unwind the cable from the winch drum.
Remove the cable end from the drum by loosening the two hex nuts. Place the cable in loose
coils on the kitchen floor.
Unfasten and retain the winch base bolts and remove the winch. Install the new winch with the
retained hardware. Rewind the cable onto the new winch drum.
Exterior Drain Hose: If a quick-disconnect coupling is damaged or the hose is cut or cracked,
no repair is possible. The hose assembly must be replaced. If a gasket is damaged, remove it
from the coupling using needle nose pliers and replace it with a new one.
Fabric Side: The shelter wing must be fully lowered and supported by wing jacks to replace the
fabric side. Remove all appliances and shelter arch components from the side to be replaced.
Starting at the top edge of the container, remove and retain the machine screws and mounting
plates along the top of the fabric side. Repeat the procedure along the sides of the container
and along the perimeter of the wing floor. Loosen the hardware holding the rubber bumper
along the edge of the wing if necessary to remove the fabric side. After all hardware has been
removed, remove the fabric side.
Unfold the replacement fabric side. Align the top of the fabric at the top of the container. While
holding the fabric side in place, install the mounting plates and machine screws along the top of
the container. Repeat the procedure along the sides of the container. Bring the material down
to the edge of the rubber bumper along the length of the wing edge and install the mounting
plates and machine screws.
Install the shelter arch components and check the alignment of the fabric side and that all
hardware has been properly installed.
0017 00-3
