CONTAINERIZED KITCHEN (CK)
OPERATION UNDER USUAL CONDITIONS
Mobile Warming Cabinet
1. Unplug the power cord, coil it, and hang it from the holder on the back of the unit.
2. Place all the baking pans except one on the bottom slides.
3. Place the cutting boards on the baking pans.
4. Install another set of slides just above the baking pans.
5. Place the remaining baking pan on the slides.
6. Place three insulated food containers on this pan.
7. Install another set of slides just above the top insulated food container.
8. Place all remaining loose slides on top of the top insulated food container.
9. Place two short rubber straps crossed over the top of the loose slides and containers. Hook
the straps to the front rack hangers. Stretch the straps across and up and hook them to the
rear rack hangers, ensuring that the strap hooks are completely hooked into holes in the
rack hangers.
10. Close and latch the warming cabinet doors.
11. Position the warming cabinet as shown earlier in Figure 15, with its back to the side of the
dual oven assembly, and strap it down with two ratchet straps run from back to front.
Mobile Storage Cabinets
1. Place four beverage dispensers on the top shelf of each storage cabinet. Strap them in
place with one short rubber strap placed across the front of the beverage dispensers.
2. Nest the 10-gallon pots inside each other. Place them and the 15-gallon pots on the bottom
shelves of the storage cabinets. Place the pot lids on top of the pots. Strap them in place
with one short rubber strap placed across the front of the pots.
3. Position the storage cabinets side by side as shown earlier in Figure 15, with their fronts
facing the cook center, and strap each down with one ratchet strap run from side to side.
Tighten the straps securely.
Hand Sink Assembly
1. Tightly coil the internal drain hose and pack it in the back of the sink assembly.
2. Tightly coil the water supply hose and connect its ends together to prevent contamination.
Tightly coil the external drain hose.
assembly.
3. Locate the sink assembly as shown earlier in Figure 15, with its back to the side of the
mobile warming cabinet, and strap it down with one ratchet strap run from side to side.
Tighten the strap securely.
TM 10-7360-226-13&P
Pack both hoses on the lower shelf of the sink
0006 00-31
0006 00
