MultiProcessor Specification
4GB
FFFF_FFFFH
FFFE_0000H
FEF0_0000H
FEE0_0000H
FED0_0000H
FEC0_0000H
1MB
0010_0000H
000F_0000H
000E_0000H
000D_0000H
000C_0000H
640K
000A_0000H
0000_0000H
PART OF THIS SPECIFICATION
UNSHADED ADDRESS REGIONS ARE FOR REFERENCE ONLY AND SHOULD NOT BE CONSTRUED AS THE SOLE
DEFINITION OF A PC/AT-COMPATIBLE ADDRESS SPACE.

3.2 System Memory Cacheability and Shareability

The cacheability and shareability of the physical memory space are defined in Table 3-1. The
address space reserved for the local APIC is used by each processor to access its own local APIC.
The address space reserved for the I/O APIC must be shareable by all processors to permit dynamic
reconfiguration.
3-2
BIOS PROM
LOCAL APIC
I/O APIC
MEMORY-MAPPED
I/O SPACE
EXTENDED
MEMORY REGION
SHADOWED BIOS
SHADOWED
EXPANSION BIOS
EXPANSION ROM
ROM EXTENSIONS
VIDEO BUFFER
SYSTEM-BASED
MEMORY
Figure 3-1. System Memory Address Map
Version 1.4
