USER
MANUAL
MH-5100 M1
MH-5100
10.1" Integrated Pad
Powered By Intel
®
Atom
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Atom MH-5100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Intel Atom MH-5100

  • Page 1 USER MANUAL MH-5100 10.1” Integrated Pad ® Powered By Intel Atom MH-5100 M1...
  • Page 2 MH-5100 10.1” Integrated Pad Powered By Intel® Atom COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in October 2017. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
  • Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 4 W/kg. Tests for SAR are conducted using standard operating positions accepted by the FCC with the EUT transmitting at the specified power level in different channels. The highest SAR value for the device as reported to the FCC is 0.573 W/kg when placed next to the body. The FCC has granted an Equipment Authorization for this device with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines.
  • Page 5: Table Of Contents

    Contents Introduction ..................1-1 About This Manual ..............1-2 Getting Started ..................2-1 Package List ................2-2 Pad System Overview (With Built-In Barcode Scanner) ... 2-3 2.2.1 Front View ................. 2-3 2.2.2 Rear View ................2-3 2.2.3 Side View ................2-4 2.2.4 Top View ................
  • Page 6 2.5.2 Front View ............... 2-11 2.5.3 Left Side View ..............2-12 2.5.4 Right Side View ............... 2-12 2.5.5 Rear View ................ 2-13 2.5.6 Bottom View ..............2-13 2.5.7 Quarter View ..............2-14 Quick Setup ................2-15 2.6.1 Turning the Power On from Pad and Connect to Wi-Fi ... 2-15 2.6.2 Turning the Power On and Connect to Local Network ..
  • Page 7 3.1.1 Power Button ..............3-2 3.1.2 DC-IN Port (DC-IN)............3-2 3.1.3 USB Port (USB1) ............... 3-2 3.1.4 Audio Port (CN_JACK1) ............ 3-3 Lite Cradle / Tiltable Cradle I/O Ports Diagram ......3-4 3.2.1 Lite Cradle I/O Ports Diagram ........... 3-4 3.2.2 Tiltable Cradle I/O Ports Diagram ........
  • Page 8 3.5.18 USB 2.0 Connector (USB1) ..........3-16 3.5.19 MSR Connector (MSR1) ..........3-17 3.5.20 SCR Connector (SCR1) ..........3-17 Daughter Board Connectors & Jumpers Quick Reference Table ....................3-18 Daughter Board MR-5100RA-1 Connectors Location..... 3-20 Setting Daughter Board MR-5100RA-1 Connectors ....3-21 3.8.1 DC IN Jack Connector (DC_IN1) ........
  • Page 9 Trigger Connector (JP2) ..........3-36 Software Utilities ................. 4-1 Introduction ................4-2 ® Installing Intel Chipset Software Installation Utility ....4-3 Installing Audio Realtek Software Installation Utility ....4-5 Installing G-Sensor Software Installation Utility ...... 4-12 Installing Bluetooth Software Installation Utility ...... 4-20 Cash Drawer API Function ............
  • Page 10 Main ................... 5-7 Advanced .................. 5-9 5.4.1 Advanced – USB Configuration ........5-10 Security ................... 5-11 Boot ..................5-13 5.6.1 Boot – EFI ................ 5-15 Exit ..................5-16 Appendix A System Diagrams ............ A-1 Integrated Pad Exploded Diagrams ............A-2 Exploded Diagram For Top Cover & Touch Panel & Panel Assembly .......................A-2 Exploded Diagram For Pad PCBA Assembly ........A-3 Exploded Diagram For Bottom Cover Assembly ......A-4...
  • Page 11 Exploded Diagram For Base Bottom Cover Assembly ....A-16 Exploded Diagram For Rotation Cover Assembly .......A-18 Exploded Diagram For Base Top Cover Assembly .....A-20 Exploded Diagram For Pad Lock Assembly ........A-21 Exploded Diagram For Holder Back Cover Assembly ....A-22 Exploded Diagram For Holder Top Cover Assembly ....A-24 Exploded Diagram For Card Holder Assembly ......A-26 Appendix B Technical Summary ..........
  • Page 12: Revision History

    Revision History The revision history of MH-5100 User Manual is described below: Version No. Revision History Date 09/06/2017 Initial Release viii...
  • Page 13: Introduction

    Introduction This chapter provides the introduction for the MH-5100 system as well as the framework of the user manual. The following topic is included: • About This Manual Page: 1-1 MH-5100 SERIES USER MANUAL...
  • Page 14: About This Manual

    Chapter 4 Software Utilities This chapter contains helpful information for proper installations of the Intel Chipset Software Installation Utility, Audio Realtek Driver Utility, G-Sensor Driver Utility, Bluetooth Driver Utility and Cash Drawer API reference.
  • Page 15: Getting Started

    Getting Started This chapter provides the information for MH-5100 system. In addition to the MH5100 Pad, users are also welcome to purchase the optional devices. This chapter describes the package contents, system overview and outlines the system specifications. The following topics are included: •...
  • Page 16: Package List

    Chapter 2 Getting Started Package List If you discover any of the items listed below are damaged or lost, please contact your local distributor immediately. Item Q’ty MH-5100 Integrated Pad Quick Reference Guide AC Power Adapter for Pad Hand Strap (optional) Neck Strap (optional) Lite Cradle (optional) Power Adapter for Lite Cradle (optional)
  • Page 17: Pad System Overview (With Built-In Barcode Scanner)

    Chapter 2 Getting Started Pad System Overview (With Built-In Barcode Scanner) Unit: mm 2.2.1 Front View Power LED 267.84 2.2.2 Rear View Smart Card Reader Camera Battery Pack Page: 2-3 MH-5100 SERIES USER MANUAL...
  • Page 18: Side View

    Chapter 2 Getting Started 2.2.3 Side View 25.2 Scan Button Scan Button Power Button USB Port DC-IN 2.2.4 Top View Built-in Barcode Scanner Earphone Jack 17.7 2.2.5 Bottom View POGO Pins Page: 2-4 MH-5100 SERIES USER MANUAL...
  • Page 19: Pad System Overview

    Chapter 2 Getting Started 2.3 Pad System Overview (With External Barcode Scanner (optional)) Unit: mm 2.3.1 Front View 2.3.2 Rear View Scan Button External Barcode Scanner (optional) Battery Pack Page: 2-5 MH-5100 SERIES USER MANUAL...
  • Page 20: Side View

    Chapter 2 Getting Started 2.3.3 Side View 25.2 Scan Button Scan Button External Barcode Scanner Power Button USB Port DC-IN 2.3.4 Top View 2.3.5 Bottom View Page: 2-6 MH-5100 SERIES USER MANUAL...
  • Page 21: Lite Cradle System Overview

    Chapter 2 Getting Started Lite Cradle System Overview Unit: mm 2.4.1 Front View 2.4.2 Rear View COM DWR IN 12V Page: 2-7 MH-5100 SERIES USER MANUAL...
  • Page 22: Side View

    Chapter 2 Getting Started 2.4.3 Side View Kensington Lock Slot 217.23 2.4.4 Top View Page: 2-8 MH-5100 SERIES USER MANUAL...
  • Page 23: Bottom View

    Chapter 2 Getting Started 2.4.5 Bottom View LAN and Cash Drawer Selection Page: 2-9 MH-5100 SERIES USER MANUAL...
  • Page 24: Quarter View

    Chapter 2 Getting Started 2.4.6 Quarter View Page: 2-10 MH-5100 SERIES USER MANUAL...
  • Page 25: Tiltable Cradle System Overview

    Chapter 2 Getting Started Tiltable Cradle System Overview Unit: mm 2.5.1 Top View External Power LED Pad Lock Barcode Scanner 2.5.2 Front View Release Switch Card Holder USB1 USB1 Page: 2-11 MH-5100 SERIES USER MANUAL...
  • Page 26: Left Side View

    Chapter 2 Getting Started 2.5.3 Left Side View DC-OUT DC-IN 12V USB4 LAN1 USB3 USB2 DC-IN LAN1 USB2 DC-OUT USB4 USB3 2.5.4 Right Side View Page: 2-12 MH-5100 SERIES USER MANUAL...
  • Page 27: Rear View

    Chapter 2 Getting Started 2.5.5 Rear View 2.5.6 Bottom View Page: 2-13 MH-5100 SERIES USER MANUAL...
  • Page 28: Quarter View

    Chapter 2 Getting Started 2.5.7 Quarter View Page: 2-14 MH-5100 SERIES USER MANUAL...
  • Page 29: Quick Setup

    Chapter 2 Getting Started Quick Setup 2.6.1 Turning the Power On from Pad and Connect to Wi-Fi Long press the Power Button on the right side of the Pad to turn on the system. Connect the Pad to a wireless network via Wi-Fi connection. (Refer to the Side View section of Pad for the location of Power Button.) How to Set Up Wi-Fi Connection Step 1.
  • Page 30: Turning The Power On And Connect To Local Network

    Chapter 2 Getting Started 2.6.2 Turning the Power On and Connect to Local Network For Lite Cradle Prerequisite: Insert a ball point pen or a pin into the hole of DWR/LAN selection switch slot located on the bottom base of the Lite Cradle, and switch it to the LAN port location.
  • Page 31 Chapter 2 Getting Started For Tiltable Cradle Press the Power Button on the right side of the Pad to turn on the system. Connect the Ethernet cable to the LAN port on the bottom left side of the Tiltable Cradle and the other end of the network cable to a port on your hub, switch or router.
  • Page 32: Installing Battery For Pad

    Chapter 2 Getting Started 2.6.3 Installing Battery for Pad Make sure to power off the device first before you start installing the battery. Step 1. Slide to unlock the left-side battery switch with your left hand. See the Figure below. Step 2.
  • Page 33: Recharging Battery From Pad

    Chapter 2 Getting Started Low Battery Indicator The low battery indicator will show on the LCD screen when the battery is nearly exhausted. When the low battery indicator appears on the tool tray, you should recharge the battery by connecting the power adapter of Pad/Lite Cradle/Tiltable Cradle or replace a fully charged battery immediately.
  • Page 34: Installing Integrated Pad Onto Lite Cradle / Tiltable Cradle

    Chapter 2 Getting Started 2.6.6 Installing Integrated Pad Onto Lite Cradle / Tiltable Cradle For Lite Cradle Step 1. From the bottom side of Pad, align the two locking tabs located on both side of the POGO pins to their mating slots located inside of Lite Cradle base respectively.
  • Page 35 Chapter 2 Getting Started For Tiltable Cradle Step 1. Place Integrated Pad into Tiltable Cradle. Step 2. Push down the Pad Lock from the top side of the Tiltable Cradle and the Pad snaps into place. See the picture below. Step 3.
  • Page 36: Separating Integrated Pad From Lite Cradle / Tiltable Cradle

    Chapter 2 Getting Started 2.6.7 Separating Integrated Pad From Lite Cradle / Tiltable Cradle For Lite Cradle Step 1. Push down the Lock Switch on the front of Lite Cradle. Step 2. Separate the integrated pad from the lite cradle. See the picture below: Push down the Lock Switch to eject.
  • Page 37 Chapter 2 Getting Started For Tiltable Cradle Step 1. Push upwards the Release Switch located on the bottom side of Tiltable Cradle. The Pad Lock on the top side of Tiltable Cradle will then release. See the System Top View picture below for the location of Release Switch.
  • Page 38: Scanning Barcodes And Qr Codes

    Chapter 2 Getting Started 2.6.8 Scanning Barcodes and QR Codes From Pad With Built-In Barcode Scanner Step 1. Press to turn on the Scan Button located on the right/left side of the Pad. (Refer to the Side View section of Pad for the location of the Scan Button.) Step 2.
  • Page 39: Installing Hand Strap

    Chapter 2 Getting Started 2.6.9 Installing Hand Strap Step 1. Tighten the two screws of the strap bracket set onto the strap bracket holes on the back cover. Step 2. Ready to hold the hand strap attached on the strap brackets to lift up the Pad with your hand.
  • Page 40: Installing Neck Strap

    Chapter 2 Getting Started 2.6.10 Installing Neck Strap Step 1. Insert one end of the provided neck strap through the upper opening of the right-side bumper rubber and adjust to tighten the neck strap. Step 2. Insert another end of the neck strap through the upper opening of the left-side bumper rubber and adjust to tighten the neck strap.
  • Page 41: Pad Specifications

    LVDS Type LED Backlight Backlight Type 10.1” PCT Touch Panel Interface BGA on board CPU Intel® Atom™ Z3736F Processor Base Frequency: 1.33 GHz Up to 1.83 GHz Intel Platform Built-in CPU Chipset DDR3L on Board 2GB DDR3L Memory Type PMIC...
  • Page 42 Chapter 2 Getting Started G-Sensor Type (Accelerator Interface sensor) LED Indicator 1. Power LED (Green): Tri-color Light LED Green / Yellow / Red a. Start OSconstant Green light b. Charging flashing Green light c. Full chargeconstant Green light 2. Alarm LED (Yellow): a.
  • Page 43 Chapter 2 Getting Started Devices (Optional) Built-in Type Honeywell 2D Barcode scanner Barcode Interface UART Scanner External Type Honeywell 2D Barcode scanner Barcode Interface UART Scanner Rear Camera Type 5M pixels module with autofocus function Interface MSR Module Type Secure head MSR (optional) (meet ISO 7811, support AAMVA / JIS II format, support single / dual / triple tracks) Interface...
  • Page 44: Lite Cradle Specifications

    Chapter 2 Getting Started Lite Cradle Specifications Lite Cradle Cradle Type POGO pins (1 x 10 pins) x 1 Connector Interface USB 2.0/Power/GND DC-IN Jack Type DC 12V IN x 1 Type Standard USB 2.0 port (Type A) x 2 Type RJ-45 with 12V/5V/RI x 1 Type...
  • Page 45: Tiltable Cradle Specifications

    Chapter 2 Getting Started Tiltable Cradle Specifications Tiltable Cradle Cradle Type POGO pins (1 x 10 pins) x 1 Connector Interface USB 2.0/Power/GND DC-IN Jack Type DC 12V In x 1 DC-Out Jack Type DC 8.4V Out x 1 Type Standard USB 2.0 port (Type A) x 4 Type RJ-45 x 1...
  • Page 46: Os Specifications

    Chapter 2 Getting Started 2.10 OS Specifications Description Windows® 10 IoT Enterprise LTSB 2016 Supports 32 bits Page: 2-32 MH-5100 SERIES USER MANUAL...
  • Page 47: Safety Precautions

    Chapter 2 Getting Started 2.11 Safety Precautions Before operating this system, read the following information carefully to protect your systems from damages, and extend the life cycle of the system. Check the Line Voltage • The operating voltage for the power supply should be within the range of 100V to 240V AC;...
  • Page 48: Hardware Configuration

    Hardware Configuration This chapter contains helpful information about the jumper & connector settings, and component locations. The following sections are included: • Pad Function Buttons and I/O Ports • Lite Cradle / Tiltable Cradle I/O Ports Diagrams • Pad Main Board Component Locations •...
  • Page 49: Pad Function Buttons And I/O Ports

    Chapter 3 Hardware Configuration Pad Function Buttons and I/O Ports 3.1.1 Power Button To turn on the system, press the Power Button on the right side of the Pad briefly. ACTION ASSIGNMENT Power Press Button Release +2.8V 3.1.2 DC-IN Port (DC-IN) Port Name: DC-IN Description: DC Power-In Port.
  • Page 50 Chapter 3 Hardware Configuration 3.1.4 Audio Port (CN_JACK1) Port Name: CN_JACK1 Description: Audio Port located on the top right side of the Pad. CN_JACK1 ASSIGNMENT LEFT RIGHT HP_DET Page: 3-3 MH-5100 SERIES USER MANUAL...
  • Page 51: Tiltable Cradle I/O Ports Diagram

    Chapter 3 Hardware Configuration Lite Cradle / Tiltable Cradle I/O Ports Diagram 3.2.1 Lite Cradle I/O Ports Diagram The I/O ports are located on the bottom side of the Lite Cradle. DC-IN RJ-45 Cash D-Sub 9 USB 2.0 Drawer Switch 3.2.2 Tiltable Cradle I/O Ports Diagram...
  • Page 52: Pad Main Board Component Locations

    Chapter 3 Hardware Configuration Pad Main Board Component Locations 3.3.1 Top View of Pad Main Board Component Locations M/B: MB-5100 Figure 3-1 MB-5100 Main Board Component Locations (Top View) WARNING: Always disconnect the power cord when you are working with the connectors on the main board. Make sure both the system and the external devices are turned OFF as sudden surge of power could ruin sensitive components.
  • Page 53: Bottom View Of Pad Main Board Component Locations

    Chapter 3 Hardware Configuration 3.3.2 Bottom View of Pad Main Board Component Locations Figure 3-2 MB-5100 Main Board Component Locations (Bottom View) Page: 3-6 MH-5100 SERIES USER MANUAL...
  • Page 54: Pad Main Board Connectors Quick Reference Table

    Chapter 3 Hardware Configuration Pad Main Board Connectors Quick Reference Table CONNECTOR Description NAME Touch Screen Connector TOUCH1 Flash Descriptor Override Selection (not used after MP) LVDS Connector LVDS1 RTC Battery Connector BAT2 Earphone Jack Connector CN_JACK1 Speaker Connector SPK1 Barcode Connector CN_BARCODE Left Scan Button...
  • Page 55: Setting Pad Main Board Connectors

    Chapter 3 Hardware Configuration Setting Pad Main Board Connectors 3.5.1 Touch Panel Connector (TOUCH1) Connector Location: TOUCH1 (rear side of mainboard) Description: Touch Panel Connector ASSIGNMENT V3P3S_TCH TOUCH1 I2C2_Touch_SCL I2C2_Touch_SDA TOUCH_INT_R TOUCH_RST_R 3.5.2 Flash Descriptor Override Selection (JP1) Connector Location: JP1 (rear side of mainboard) Description: Flash BIOS Connector ASSIGNMENT ASSIGNMENT...
  • Page 56: Lvds Connector (Lvds1)

    Chapter 3 Hardware Configuration 3.5.3 LVDS Connector (LVDS1) Connector Location: LVDS1 (rear side of mainboard) Description: LVDS (Low-Voltage Differential Signaling) Connector LVDS1 ASSIGNMENT LVDS_VCC LVDS_VCC LVDS_A_N0 LVDS_A_P0 LVDS_A_N1 LVDS_A_P1 LVDS_A_N2 LVDS_A_P2 LVDS_A_CLK_N LVDS_A_CLK_P LVDS_A_N3 LVDS_A_P3 Page: 3-9 MH-5100 SERIES USER MANUAL...
  • Page 57: Rtc Battery Connector (Bat2)

    Chapter 3 Hardware Configuration ASSIGNMENT LVDS_BKLT_CTRL VLED VLED VLED 3.5.4 RTC Battery Connector (BAT2) Connector Location: BAT2 (rear side of mainboard) Description: RTC (Real-Time Clock) Battery Connector The RTC battery provides power supply for the internal real-time clock and calendar. BAT2 ASSIGNMENT 3.5.5 Earphone Jack Connector (CN_JACK1)
  • Page 58: Speaker Connector (Spk1)

    Chapter 3 Hardware Configuration 3.5.6 Speaker Connector (SPK1) Connector Location: SPK1 (rear side of mainboard) Description: Speaker Connector ASSIGNMENT ASSIGNMENT LEFT_SPK RIGHT_SPK SPK1 3.5.7 Barcode Scanner Connector (CN_BARCODE) Connector Location: CN_BARCODE (rear side of mainboard) Description: Barcode Scanner Connector ASSIGNMENT VCC3_3 CN_BARCODE Power Down...
  • Page 59: Left Scan Button (Button1)

    Chapter 3 Hardware Configuration 3.5.8 Left Scan Button (BUTTON1) Connector Location: BUTTON1 (top side of mainboard) Description: Left Scan Button ASSIGNMENT SCAN_EN_SW BUTTON1 3.5.9 Right Scan Button (BUTTON2) Connector Location: BUTTON2 (top side of mainboard) Description: Right Scan Button ASSIGNMENT SCAN_EN_SW BUTTON2 Power Button (BUTTON4)
  • Page 60: Battery Connector (Bat1)

    Chapter 3 Hardware Configuration 3.5.11 Battery Connector (BAT1) Connector Location: BAT1 (rear side of mainboard) Description: Battery Connector ASSIGNMENT BAT1_SENSE BAT_DET BAT1 BAT_SCL BAT_SDA 3.5.12 DC IN Jack Connector (DC_IN1) Connector Location: DC_IN1 (top side of mainboard) Description: DC IN Jack Connector ASSIGNMENT ASSIGNMENT DC_IN1...
  • Page 61: Cradle Connector (Cradle1)

    Chapter 3 Hardware Configuration 3.5.13 Cradle Connector (CRADLE1) Connector Location: CRADLE1 (top side of mainboard) Description: Cradle Connector ASSIGNMENT CRA_DCIN CRADLE1 CRA_DCIN USB_DP USB_DP USB_DN USB_DN V5P0S 3.5.14 MCU F/W Update Connector (JP5) Connector Location: JP5 (rear side of mainboard) Description: MCU Firmware Update Connector ASSIGNMENT MCU_MISO...
  • Page 62: Battery Lock Switch Button (Bat_Lock)

    Chapter 3 Hardware Configuration 3.5.15 Battery Lock Switch Button (BAT_LOCK) Connector Location: BAT_LOCK (rear side of mainboard) Description: Battery Lock Switch Button ASSIGNMENT ASSIGNMENT BAT_LOCK BAT_LOCK 3.5.16 MicroSD Card Connector (J2) Connector Location: J2 (rear side of mainboard) Description: MicroSD (Secure Digital) Card Connector ASSIGNMENT DAT2 CD/DAT3...
  • Page 63: Ccd Front Camera Connector (Ccm1)

    Chapter 3 Hardware Configuration 3.5.17 CCD Front Camera Connector (CCM1) Connector Location: CCM1 (rear side of mainboard) Description: CCD (Charge-coupled Device) Front Camera Connector ASSIGNMENT CCM_DP CCM_DN CCM1 VCAM 3.5.18 USB 2.0 Connector (USB1) Connector Location: USB1 (top side of mainboard) Description: USB 2.0 Connector ASSIGNMENT USB_DP...
  • Page 64: Msr Connector (Msr1)

    Chapter 3 Hardware Configuration 3.5.19 MSR Connector (MSR1) Connector Location: MSR1 (rear side of mainboard) Description: MSR (Magnetic-Stripe Card Reader) Connector ASSIGNMENT MSR_DN MSR_DP MSR1 3.5.20 SCR Connector (SCR1) Connector Location: SCR1 (rear side of mainboard) Description: SCR Connector ASSIGNMENT SCR_DN SCR_DP SCR1...
  • Page 65: Daughter Board Connectors & Jumpers Quick Reference Table

    Chapter 3 Hardware Configuration Daughter Board Connectors & Jumpers Quick Reference Table MR-5100RA-1 Connectors List (for Tiltable Cradle) CONNECTOR Description NAME DC IN Jack Connector DC_IN1 DC OUT Jack Connector DC_OUT Universal Serial Bus 2.0 Connector USB1 Universal Serial Bus 2.0 Connector USB2 Universal Serial Bus 2.0 Connector USB3...
  • Page 66 Chapter 3 Hardware Configuration MR-5100RA-5 Jumpers List (For Lite Cradle) JUMPER Description NAME COM1 Port Pin9 Definition Selection JP_COM1 Guide (MR-5100RA-5) COM2 Port Pin9 Definition Selection JP_COM2 Guide (MR-5100RA-5) MR-5100RA-3 Connectors List (for External Barcode Scanner (optional)) CONNECTOR Description NAME Barcode Scanner Connector CN_BARCODE1 Barcode Scanner Connector...
  • Page 67 Chapter 3 Hardware Configuration Daughter Board MR-5100RA-1 Connectors Location Figure 3-3 MR-5100RA-1 Daughter Board Component Locations (Top View) Figure 3-4 MR-5100RA-1 Daughter Board Component Locations (Bottom View) Page: 3-20 MH-5100 SERIES USER MANUAL...
  • Page 68: Dc Out Jack Connector (Dc_Out)

    Chapter 3 Hardware Configuration Setting Daughter Board MR-5100RA-1 Connectors 3.8.1 DC IN Jack Connector (DC_IN1) Connector Location: DC_IN1 Description: DC IN Jack Connector. The DC_IN1 port is located on the bottom left side of Tiltable Cradle. DC_IN1 ASSIGNMENT VCC12V 3.8.2 DC Out Jack Connector (DC_OUT) Connector Location: DC_OUT Description: DC Out Jack Connector.
  • Page 69: Universal Serial Bus 2.0 Connector (Usb2)

    Chapter 3 Hardware Configuration 3.8.4 Universal Serial Bus 2.0 Connector (USB2) Connector Location: USB2 Description: USB 2.0 Connector. The USB2 port is located on the bottom left side of Tiltable Cradle. ASSIGNMENT VCC5V USB2 3.8.5 Universal Serial Bus 2.0 Connector (USB3) Connector Location: USB3 Description: USB 2.0 Connector.
  • Page 70: Lan Port (Lan1)

    Chapter 3 Hardware Configuration 3.8.7 LAN Port (LAN1) Port Name: LAN1 Description: LAN RJ-45 Port (bottom left I/O) PIN ASSIGNMENT MDIP0 MDIN0 MDIP1 MDIN1 Green Yellow MDIP2 LAN1 MDIN2 MDIP3 MDIN3 LAN LED Indicator: Right Side LED Yellow Color Blinking LAN Message Active No LAN Message Active Left Side LED...
  • Page 71: Daughter Board Mr-5100Ra-2 Connectors Location

    Chapter 3 Hardware Configuration Daughter Board MR-5100RA-2 Connectors Location Figure 3-5 MR-5100RA-2 Daughter Board Component Locations (Top View) Figure 3-6 MR-5100RA-2 Daughter Board Component Locations (Bottom View) Page: 3-24 MH-5100 SERIES USER MANUAL...
  • Page 72: Lite Cradle / Tiltable Cradle Connector (Cradle1)

    Chapter 3 Hardware Configuration 3.10 Setting Daughter Board MR-5100RA-2 Connector 3.10.1 Lite Cradle / Tiltable Cradle Connector (CRADLE1) Connector Location: CRADLE1 Description: Lite Cradle / Tiltable Cradle Connector CRADLE1 ASSIGNMENT CRA_DCIN CRA_DCIN USB_DP USB_DP USB_DN USB_DN V5P0S Page: 3-25 MH-5100 SERIES USER MANUAL...
  • Page 73: Daughter Board Mr-5100Ra-3 Connectors Location

    Chapter 3 Hardware Configuration 3.11 Daughter Board MR-5100RA-3 Connectors Location CNB_BARCODE1 CNB_BARCODE2 Figure 3-7 MR-5100RA-3 Daughter Board Component Locations (Top View) Page: 3-26 MH-5100 SERIES USER MANUAL...
  • Page 74: Setting Daughter Board Mr-5100Ra-3 Connectors

    Chapter 3 Hardware Configuration 3.12 Setting Daughter Board MR-5100RA-3 Connectors 3.12.1 Barcode Scanner Connector (CN_BARCODE1) Connector Location: CN_BARCODE1 Description: Barcode Scanner Connector ASSIGNMENT VCC3_3 Power Down CN_BARCODE1 Buzzer LED_Output Wake up Trigger 3.12.2 Bar Code Scanner Connector (CN_BARCODE2) Connector Location: CN_BARCODE2 Description: Barcode Scanner Connector ASSIGNMENT VCC3_3...
  • Page 75: Trigger Connector (Jp1)

    Chapter 3 Hardware Configuration 3.12.3 Trigger Connector (JP1) Connector Location: JP1 Description: Trigger Connector ASSIGNMENT Trigger 3.12.4 Trigger Connector (JP2) Connector Location: JP2 Description: Trigger Connector ASSIGNMENT Trigger Page: 3-28 MH-5100 SERIES USER MANUAL...
  • Page 76: Daughter Board Mr-5100Ra-5 Connectors & Jumpers Location

    Chapter 3 Hardware Configuration 3.13 Daughter Board MR-5100RA-5 Connectors & Jumpers Location JP_COM1 Pin9 RI/5V/12V JP_COM2 Pin9 RI/5V/12V (default) (default) EEPROM_CN1 ESD4 JP_COM1 JP_COM2 (RJ-45) (D-Sub 9) Note: When the Lite Cradle is joined with Integrated Pad, the COM2 and COM3 ports shown on Pad system are actually COM1 and COM2 ports of the daughter board respectively, because the Lite Cradle’s COM ports are deployed according to OS Image built by Protech and COM1 port placement has been...
  • Page 77 Chapter 3 Hardware Configuration M/N: ECN: S/N: Figure 3-8 MR-5100RA-5 Daughter Board Component Locations (Bottom View) Page: 3-30 MH-5100 SERIES USER MANUAL...
  • Page 78: Com1, Com2 Port Pin9 Definition Selection Guide

    Chapter 3 Hardware Configuration 3.14 Setting Daughter Board MR-5100RA-5 Connectors and Jumpers 3.14.1 COM1, COM2 Port Pin9 Definition Selection Guide JP_COM1 and JP_COM2) Jumper Location: JP_COM1 and JP_COM2 Description: COM1, COM2 Port Pin9 RI/+5V/+12V Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION (Default Setting) JP_COM1 JP_COM2 JP_COM1 JP_COM2...
  • Page 79: Com Port (Com1)

    Chapter 3 Hardware Configuration 3.14.2 RJ-45 COM Port (COM1) COM1(RS-232, RJ-45) Connector Pin Assignment ASSIGNMENT ASSIGNMENT COM1 RI/5V/12V Note: COM1 Pin 9 is selectable for RI, +5V or +12V by jumper setting. Default setting is RI. Please see “COM1, COM2 Port Pin9 Definition Selection Guide” section for selection details.
  • Page 80: Dual Usb Ports

    Chapter 3 Hardware Configuration 3.14.4 DC-IN Port (DC_IN1) Port Name: DC_IN1 Description: DC Power-In Port. The DC-IN Port is located on the bottom side of Lite Cradle. ASSIGNMENT VCC12V DC_IN1 Dual USB Ports 3.14.5 Port Name: USB1 Description: Dual USB 2.0 Type A Connectors ASSIGNMENT ASSIGNMENT VCC5V...
  • Page 81: Local Area Network (Lan) Port (Lan1)

    Chapter 3 Hardware Configuration 3.14.6 Local Area Network (LAN) Port (LAN1) Port Name: LAN1 Description: a Giga LAN RJ-45 Port ASSIGNMENT MX0+ MX0- Green/Orange MX1+ LAN1 MX1- SPEED_LED VCC3.3V LINK_ACT_LED VCC3.3V LAN LED Status There are 2 LAN LED indicators for LAN on the bottom side of the Lite Cradle. By observing their status, you can know the status of the Ethernet connection.
  • Page 82: Cash Drawer Port (Drw1)

    Chapter 3 Hardware Configuration 3.14.7 Cash Drawer Port (DRW1) Port Name: DRW1 Description: RJ-11 Cash Drawer Port ASSIGNMENT DRAWER_OPEN DRAWER_SENSE VCC12V DRW1 3.14.8 LAN & Cash Drawer Function Switch (SW1) Connector Name: SW1 Description: LAN Port and Cash Drawer function selection ASSIGNMENT CASH DRAWER Note: Users need to use a ball point pen or a pin to toggle the DIP switch.
  • Page 83: Daughter Board Mr-5100Ra-8 Connectors Location

    Chapter 3 Hardware Configuration 3.15 Daughter Board MR-5100RA-8 Connectors Location Figure 3-9 MR-5100RA-8 Daughter Board Component Locations (Top View) 3.16 Setting Daughter Board MR-5100RA-8 Connectors 3.16.1 Barcode Scanner Function Switch Connector (SW1) Connector Location: SW1 Description: Barcode Scanner Function Switch Connector ASSIGNMENT Click Trigger...
  • Page 84: Software Utilities

    This chapter provides the detailed information that guides users to install driver utilities for the system. The following topics are included: • Installing Intel ® Chipset Software Installation Utility • Installing Audio Realtek Software Installation Utility • Installing G-Sensor Software Installation Utility •...
  • Page 85: Introduction

    File Path: C:\MH-5100_v1.0 Win10 Filename Purpose 32-bit (Assume that drive is C:) Intel® Chipset Device Software installer C:\MH-5100_v1.0\DRIVER\ (Audio & BM& DPTF & GFX & GPIO &  Platform\1_Main Chip GPIO & I2C & MBI & PMIC & Sensor &...
  • Page 86: Installing Intel ® Chipset Software Installation Utility

    Chipset Software Installation Utility installs the Windows *.INF files to the target system. These files outline to the operating system how to configure the Intel chipset components in order to ensure that the following functions work properly: Core PCI and ISAPNP Services •...
  • Page 87 Chapter 4 Software Utilities After the Chipset driver is installed, the following driver utilities will also be installed at the same time: Audio driver utility • BM driver utility • DPTF driver utility • GFX driver utility • GPIO driver utility •...
  • Page 88: Installing Audio Realtek Software Installation Utility

    Chapter 4 Software Utilities Installing Audio Realtek Software Installation Utility After the default Audio driver utility has been installed in the procedure above, it will not function until you have installed Realtek ALC5640-VB-CG driver utilities. Please follow the steps below: Enter the C:\MH-5100_v1.0 >...
  • Page 89 Chapter 4 Software Utilities Page: 4-6 MH-5100 SERIES USER MANUAL...
  • Page 90 Chapter 4 Software Utilities From Realtek I2S Audio Codec Properties window, click Update Driver… from the Driver tab to start updating the audio driver software for MH-5100. Click Browse my computer for driver software item. Page: 4-7 MH-5100 SERIES USER MANUAL...
  • Page 91 Chapter 4 Software Utilities Click Let me pick from a list of device drivers on my computer. Click Have Disk…. Page: 4-8 MH-5100 SERIES USER MANUAL...
  • Page 92 Chapter 4 Software Utilities Click Browse... button to browse for the file directory where the Realtek I2S Audio Codec installation driver is located. Select C:\MH-5100_v1.0 > DRIVER > Platform > 2_Audio > Win10-32Bit > RTK_6_2_9600_4239_WHQL> x86, select rtii2sac.inf file and click Open to open the file. Page: 4-9 MH-5100 SERIES USER MANUAL...
  • Page 93 Chapter 4 Software Utilities Click OK. Click Next to continue the installation. Page: 4-10 MH-5100 SERIES USER MANUAL...
  • Page 94 Chapter 4 Software Utilities Windows has finished installing Realtek I2S Audio Codec driver software. Click Close to complete. Go to Realtek I2S Audio Codec Properties window and select Driver tab, and you will see the Realtek audio driver utility has been updated.
  • Page 95: Installing G-Sensor Software Installation Utility

    Chapter 4 Software Utilities Once the installation is completed, restart MH-5100 for the changes to take effect, and the audio function can start to work normally. Installing G-Sensor Software Installation Utility The G-Sensor driver utility provided allows users to turn the touch screen horizontally or vertically.
  • Page 96 Chapter 4 Software Utilities Page: 4-13 MH-5100 SERIES USER MANUAL...
  • Page 97 Chapter 4 Software Utilities From STMicroelectronics 3-Axis Digital Accelerometer Properties window, click Update Driver… from the Driver tab to start install the G-sensor driver software for MH-5100. Click Browse my computer for driver software item. Page: 4-14 MH-5100 SERIES USER MANUAL...
  • Page 98 Chapter 4 Software Utilities Click Let me pick from a list of device drivers on my computer. Click Have Disk… button. Page: 4-15 MH-5100 SERIES USER MANUAL...
  • Page 99 Chapter 4 Software Utilities Click Browse… button to browse for the file directory where the G-sensor installation driver is located. Select C:\MH-5100_v1.0 > DRIVER > Device > G-sensor > Win10-32Bit >2_Accel_SPB_SensorAPI_2.8.1.10(STEP-2) > x86 folder from the Look in drop-down box, and select ST_Accel.inf file.
  • Page 100 Chapter 4 Software Utilities Click OK. Click Next to continue the installation. Page: 4-17 MH-5100 SERIES USER MANUAL...
  • Page 101 Chapter 4 Software Utilities Windows has finished installing G-sensor driver software. Click Close to complete. Page: 4-18 MH-5100 SERIES USER MANUAL...
  • Page 102 Chapter 4 Software Utilities Go to STMicroelectronics 3-Axis Digital Accelerometer Properties window and select Driver tab, and you will see the STMicroelectronics G-sensor driver utility has been updated. Click Close to exit. Once the installation is completed, restart MH-5100 for the changes to take effect.
  • Page 103: Installing Bluetooth Software Installation Utility

    Chapter 4 Software Utilities Installing Bluetooth Software Installation Utility Please follow the steps below to install Bluetooth driver utilities: Enter the C:\MH-5100_v1.0 > DRIVER > Platform > 4_Bluetooth > Win10-32Bit > BTW12.0.1.720_Win10_UART_USI folder. Click Setup.exe file for driver installation. Follow the on-screen instructions to install the Bluetooth driver. Once the installation is completed, restart MH-5100 for the changes to take effect.
  • Page 104: Cash Drawer Api Function

    Chapter 4 Software Utilities Cash Drawer API Function Init_Drawer int Init_Drawer(void); Purpose Initialize the Cash Drawer. Return True (1) on success, False (0) on failure Example if (Init_Drawer() > 0) { //"Success!" } else { //"Failure!" Release_Drawer int Release_Drawer(void); Purpose Release the Cash Drawer.
  • Page 105 Chapter 4 Software Utilities Drawer_Open int Drawer_Open(unsigned char channel, unsigned char time); Purpose Open the Cash Drawer. Value channel = 0 (Open the Cash Drawer1 <hardware is disabled>) channel = 1 (Open the Cash Drawer2) time:Parameter range is 5~50, unit is 10 millisecond. (Time range:...
  • Page 106: Bios Setup

    BIOS SETUP This chapter guides users how to configure the basic system configurations via the BIOS Setup Utilities. The information of the system configuration is saved in BIOS NVRAM so that the Setup information is retained when the system is powered off. The BIOS Setup Utilities consist of the following menu items: Main Menu •...
  • Page 107: Introduction

    Chapter 5 BIOS Setup Introduction The board MH-5100 <Intel® Atom™ > uses an Insyde BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the BIOS Setup program, Power-on Self-Test (POST), the PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.
  • Page 108: Accessing Setup Utility

    Chapter 5 BIOS Setup The BIOS setup menu allows users to view and modify the BIOS settings for the computer. After the system is powered on, users can access the BIOS setup menu by pressing <Del> or <Esc> immediately while the POST message is running before the operating system is loading.
  • Page 109 Chapter 5 BIOS Setup Figure 5-3. Front Page Screen Page: 5-4 MH-5100 SERIES USER MANUAL...
  • Page 110 Build Date 05/11/2017 language used by the Build Time 14:10:19 InsydeH20. MCU Version: 170210 Processor Type Intel® Atom™ CPU Z3736F @ 1.33 GHz 83 MHz System Bus Speed System Memory Speed 1333 MHz Cache RAM 1024 KB Total Memory 2048 MB...
  • Page 111 Chapter 5 BIOS Setup BIOS Setup Description Navigation Key <←> and <→> Select a different menu screen (move the cursor from the selected menu to the left or right). <↑> and <↓> Select a different item (move the cursor from the selected item upwards or downwards) <Enter>...
  • Page 112: Main

    Build Date 05/11/2017 language used by the Build Time 14:10:19 InsydeH20. MCU Version: 170210 Processor Type Intel® Atom™ CPU Z3736F @ 1.33 System Bus Speed GHz 83 MHz System Memory Speed 1333 MHz Cache RAM 1024 KB Total Memory 2048 MB...
  • Page 113 Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose VGFX value No changeable options Displays the current VGFX voltage. VCore value No changeable options Displays the current VCore voltage. VDDR value No changeable options Displays the current VDDR voltage. English, Francais, End users can select from four Language Chinese, Japanese...
  • Page 114: Advanced

    Chapter 5 BIOS Setup Advanced Menu Path Advanced This menu provides advanced configurations for setting USB Configuration. InsydeH20 Setup Utility Rev. 5.0 Main Advanced Security Boot Exit ►USB Configuration Help Select Item F5/F6 Change Values Setup Defaults Exit Select Menu Enter Select ►SubMenu Save and Exit...
  • Page 115: Advanced - Usb Configuration

    Chapter 5 BIOS Setup 5.4.1 Advanced – USB Configuration Menu Path Advanced > USB Configuration The USB Configuration allows users to configure advanced USB settings such as enabling/disabling xHCI (Extensible Host Controller Interface) Controller and xHCI Mode. InsydeH20 Setup Utility Rev.
  • Page 116: Security

    Chapter 5 BIOS Setup Security Menu Path Security From the Security menu, you are allowed to create, change or clear the supervisor password. You will be asked to enter the configured supervisor password before you can access the Setup Utility. By setting a supervisor password, you will prevent other users from changing your BIOS settings.
  • Page 117 Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose Set Supervisor Password Password can be 1-20 Specifies the administrator alphanumeric characters. password. Set User Password Password can be 1-20 Specifies the user password. alphanumeric characters. Page: 5-12 MH-5100 SERIES USER MANUAL...
  • Page 118: Boot

    Chapter 5 BIOS Setup Boot Menu Path Boot This menu provides control items for system boot configuration such as setting setup prompt timeout, enabling/disabling quick boot, quiet boot, Network Stack and PXE Boot capability, adding boot options, configuring ACPI (Advanced Configuration and Power Management Interface) settings, USB boot and EFI device first.
  • Page 119 Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose UEFI IPv4/IPv6 PXE • Legacy PXE OPROM • PXE Boot capability - Enabled Disabled: Supports Network • - Disabled Stack UEFI PXE: IPv4/IPv6 • Legacy: Legacy PXE OPROM • only Add Boot Options - First Position in Boot order for shell, - Last...
  • Page 120: Boot - Efi

    Chapter 5 BIOS Setup 5.6.1 Boot – EFI Menu Path Boot > EFI The EFI allows users to view the boot devices. InsydeH20 Setup Utility Rev. 5.0 Boot Windows Boot Manager EFI USB Device (SanDisk) Help Select Item F5/F6 Change Values Setup Defaults Exit Select Menu...
  • Page 121: Exit

    Chapter 5 BIOS Setup Exit Menu Path Exit The Exit allows users to save or discard changed BIOS settings as well as load the optimized defaults for BIOS settings. Save Changed BIOS Settings To save and validate the changed BIOS settings, select Exit Saving Changes (or press F10) to validate the changes and then exit the system.
  • Page 122 Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose Exits and discard Changes done so Exit Discarding Changes No changeable options far to any of the setup options. Loads the optimized defaults for Load Optimal Defaults No changeable options BIOS settings. Page: 5-17 MH-5100 SERIES USER MANUAL...
  • Page 123: Appendix A System Diagrams

    Appendix A System Diagrams This appendix contains exploded diagrams and part numbers of the Pad, Lite Cradle and Tiltable Cradle for MH-5100 system. The following topics are included: Exploded Diagrams for Integrated Pad Exploded Diagram for Top Cover, Touch Panel and Panel •...
  • Page 124: Integrated Pad Exploded Diagrams

    Appendix A System Diagrams Integrated Pad Exploded Diagrams Exploded Diagram For Top Cover & Touch Panel & Panel Assembly ITEM Description Part No. Q’ty Touch Panel 52-380-14164023 Panel 52-351-12101028 MH-5100 Top Cover 30-002-12210378 MH-5100 Bumper Right 30-013-48300378 MH-5100 Bumper Left 30-013-48200378 MH-5100 Barcode Button 30-046-28110378...
  • Page 125: Exploded Diagram For Pad Pcba Assembly

    Appendix A System Diagrams Exploded Diagram For Pad PCBA Assembly ITEM Description Part No. Q’ty MH-5100 Panel Holder 20-029-34001378 Round Head With Spring Washer Screw 22-235-25006011 (M2.5x0.45Px6mm) MH-5100 PCBA Round Head With Spring Washer Screw 22-232-20005311 (M2x0.4Px5mm) Sub-Battery 27-061-37801071 Thermal Pad 20x15mm 81-006-82015001 Thermal Pad 15x15mm 81-006-81515005...
  • Page 126: Exploded Diagram For Bottom Cover Assembly

    Appendix A System Diagrams Exploded Diagram For Bottom Cover Assembly ITEM Description Part No. Q’ty MH-5100 Bottom Cover 30-002-12110378 MH-5100 Slide Key 30-002-28410378 MH-5100 Battery Hook 90-019-04110378 MH-5100 Battery Hook (Lock) 90-019-04210378 MH-5100 Battery Lock Spring 23-002-00000332 Round Washer Head Screw #1/T2.0x5mm 22-132-20005011 MH-5100 MSR-Bumper-Rubber 30-013-48100378...
  • Page 127: Exploded Diagram For Camera Module & Barcode Scanner Module

    Appendix A System Diagrams Exploded Diagram For Camera Module & Barcode Scanner Module Assembly ITEM Description Part No. Q’ty Camera PCBA 52-151-08040533 Round Head Screw 22-232-20004811 φ3.3/#1/M2x0.4Px4mm Barcode Module 52-820-36800111 MH-5100 Barcode Fix Plate 80-005-03001378 Fillister Head Screw T1.7xL4mm 22-175-17004011 Round Head With Spring Washer Screw 22-232-20005311 (M2x0.4px5mm)
  • Page 128: Exploded Diagram For Back Cover Assembly

    Appendix A System Diagrams Exploded Diagram For Back Cover Assembly ITEM Description Part No. Q’ty MH-5100 Decoration Cover 30-002-28110378 Round Head With Spring Washer Screw 22-235-25006011 (M2.5x0.45Px6mm) MH-5100 –Screw-Hole-Plug 30-013-06100378 MH-5100 Strap Bracket 80-006-06001378 Pan Head Screw M3x0.5Px6mm 22-220-30006011 M2xL3mm Flat-Head-Screw 22-215-20003011 Page: A-6 MH-5100 SERIES USER MANUAL...
  • Page 129: Exploded Diagram For Smart Card Reader Assembly

    Appendix A System Diagrams Exploded Diagram For Smart Card Reader Assembly ITEM Description Part No. Q’ty MH-5100 Smart Card Cover 30-002-28610378 Round Head Screw φ3.3 / #1 / 22-232-20004811 M2x0.4Px4mm Smart Card Module 52-551-16000010 Pan Head Screw (T2.0x4mm) 22-125-20004011 Page: A-7 MH-5100 SERIES USER MANUAL...
  • Page 130 Appendix A System Diagrams Exploded Diagram For External Barcode Scanner Assembly (1) Component Name P/N No. Q’ty FILLISTER HEAD 22-175-20004011 SCREW#0/T2x4mm BARCODE SCANNER MODULE 52-820-36800111 BARCODE BARACKET 80-006-03002378 FLAT HEAD SCREW T1.7x4mm 22-115-17004011 BARCODE BOTTOM COVER 30-002-28114378 Page: A-8 MH-5100 SERIES USER MANUAL...
  • Page 131: Exploded Diagram For External Barcode Scanner Assembly (1

    Appendix A System Diagrams Exploded Diagram For External Barcode Scanner Assembly (2) Component Name P/N No. Q’ty FLAT HEAD SCREW 22-212-20003011 M2x0.4Px3mm BARCODE TOP BRACKET 80-006-03003378 MR-5100RX-3-PCB MR-5100RA-31N FILLISTER HEAD 22-175-20004011 SCREW/T2.9x4mm BARCODE TOP COVER 30-002-28115378 Page: A-9 MH-5100 SERIES USER MANUAL...
  • Page 132: Exploded Diagram For External Barcode Scanner Assembly (2

    Appendix A System Diagrams Exploded Diagram For External Barcode Scanner Assembly (3) Component Name P/N No. Q’ty Round Head With Spring Washer 22-235-25006011 Screw (M2.5x0.45Px6mm) ROUND HEAD SCREW 22-232-20004811 φ3.3/#1/M2x0.4Px4mm Page: A-10 MH-5100 SERIES USER MANUAL...
  • Page 133: Exploded Diagram For Scan Button Assembly

    Appendix A System Diagrams Exploded Diagram For Scan Button Assembly Page: A-11 MH-5100 SERIES USER MANUAL...
  • Page 134 Appendix A System Diagrams ITEM Description Part No. Q’ty MH-5100 Bottom Cover (VR(PANTONE 30-002-12410378 White 5315U) MH-5100 Slide Key-(PANTONE 5315U) 30-002-28810378 MH-5100 Battery Hook 90-019-04110378 MH-5100 Battery Hook (Lock) 90-019-04210378 MH-5100 Battery Lock Spring 23-002-00000332 Round Washer Head Screw #1/T2.0x5mm 22-132-20005011 MH-5100 Barcode-Button-Rubber 90-013-01300378...
  • Page 135: Lite Cradle Exploded Diagrams

    Appendix A System Diagrams Lite Cradle Exploded Diagrams Exploded Diagram For Cradle Top Cover Assembly Page: A-13 MH-5100 SERIES USER MANUAL...
  • Page 136 Appendix A System Diagrams ITEM Description Part No. Q’ty MH-5100-Lite-Cradle-Top-Cover 30-002-28310378 MH-5100-Lite-Cradle-Rear-Cover 30-002-28210378 T2.6xL8mm Pan-Head-Screw 22-135-26008011 POGO Pin PCBA 10-625-01010025 MH-5100-Lite-Cradle-Hole-Cover 30-002-28510378 Pan Head screw (T2.0x4mm) 22-125-20004011 MH-5100-Lite-Cradle-Ejection-Spring 23-000-00010622 MH-5100-Lite-Cradle-Lock-Button 30-046-09230378 MH-5100-Lite-Cradle-Button-Hook 30-046-09130378 MT-590X Battery Lock Spring 23-000-01000132 MH-5100-Lite-Cradle-Lock-Spring-Cover 80-004-03001378 MH-5100-Lite-Cradle-Rotate-Plate 80-005-03002378 T2.3xL5mm Pan-Head-Screw...
  • Page 137: Exploded Diagram For Cradle Pcba & Bottom Cover Assembly

    Appendix A System Diagrams Exploded Diagram For Cradle PCBA & Bottom Cover Assembly ITEM Description Part No. Q’ty MH-5100-Lite-Cradle-Metal-Plate 80-005-03003378 Lite Cradle PCBA Round Washer Head Screw 22-232-30006311 (M3x0.5Px6mm) T2.6xL8mm Flat-Head-Screw 22-115-26008011 Rubber Foot φ=16x3.5mm (Black) 30-004-06800000 Page: A-15 MH-5100 SERIES USER MANUAL...
  • Page 138: Tiltable Cradle Exploded Diagrams

    Appendix A System Diagrams Tiltable Cradle Exploded Diagrams Exploded Diagram For Base Bottom Cover Assembly Page: A-16 MH-5100 SERIES USER MANUAL...
  • Page 139 Appendix A System Diagrams Component Name P/N No. Q’ty BASE BOT 30-027-28160378 KING LOCK PLATE 80-005-03006378 TAPPING 3xL5 22-121-30005011 BOTTOM PLATE 80-005-03004378 CABLE CLAMP 90-023-04100378 TAPPING 3xL8 22-122-30008005 PCBA MR-5100RA-11N SCREW M3xL5 22-242-30005311 CRADLE BASE BRACKET 80-006-03001378 SCREW M3xL6 22-232-30060211 Page: A-17 MH-5100 SERIES USER MANUAL...
  • Page 140: Exploded Diagram For Rotation Cover Assembly

    Appendix A System Diagrams Exploded Diagram For Rotation Cover Assembly Page: A-18 MH-5100 SERIES USER MANUAL...
  • Page 141 Appendix A System Diagrams Component Name P/N No. Q’ty CRADLE-STAND 80-017-01001378 BEARING 30-002-09130378 CUSHION 30-013-06110378 SPRING PLATE 80-005-06001378 SCREW M2xL3 22-212-20003911 SCREW M4xL8 22-232-40008211 ROTATION COVER R 30-002-28111378 ROTATION-COVER-R-ANY 30-002-14230378 TAPPING T2.5xL5 22-172-25005011 ROTATION-COVER-L 30-002-12130378 ROTATION-COVER-L-ANY 30-002-14130378 CRADLE-STAND-PLATE 80-005-03005378 SCREW M3xL6 22-272-30006311 BASE SPHERE RIGHT 30-027-28210378...
  • Page 142: Exploded Diagram For Base Top Cover Assembly

    Appendix A System Diagrams Exploded Diagram For Base Top Cover Assembly Component Name P/N No. Q’ty BASE TOP 30-027-28310378 TAPPING T3xL5 22-121-30005011 RUBBER FOOT (Φ 17.5x5.3mm) 30-004-06100378 Page: A-20 MH-5100 SERIES USER MANUAL...
  • Page 143: Exploded Diagram For Pad Lock Assembly

    Appendix A System Diagrams Exploded Diagram For Pad Lock Assembly Component Name P/N No. Q’ty HOLDER_LOCK_TOP 30-012-28410378 HOLDER-LOCK-BOTTOM 30-012-28310378 TAPPING T2.5xL5 22-172-25005011 Page: A-21 MH-5100 SERIES USER MANUAL...
  • Page 144: Exploded Diagram For Holder Back Cover Assembly

    Appendix A System Diagrams Exploded Diagram For Holder Back Cover Assembly Page: A-22 MH-5100 SERIES USER MANUAL...
  • Page 145 Appendix A System Diagrams Component Name P/N No. Q’ty HOLDER_BACK_COVER 30-012-28110378 SWITCH 30-002-28113378 SWITCH-REPOSITION 30-002-28112378 BUTTON-SPRING 23-002-00000142 PUSH-BUTTON-PLATE 80-005-03007378 TAPPING T2.5xL5 22-172-25005011 CABLE CLAMP 90-023-04100378 SCREW M3xL5 22-242-30005311 HOLDER-LOCK-SPRING 23-002-00000252 HOLDER_LOCK_CASE 80-032-03001378 TAPPING T2.6xL5 22-132-26005011 Page: A-23 MH-5100 SERIES USER MANUAL...
  • Page 146: Exploded Diagram For Holder Top Cover Assembly

    Appendix A System Diagrams Exploded Diagram For Holder Top Cover Assembly Page: A-24 MH-5100 SERIES USER MANUAL...
  • Page 147 Appendix A System Diagrams Component Name P/N No. Q’ty SCREW M3xL10 22-272-30010018 CRADLE CHARGE PCB TAPPING T2xL3 22-172-20003011 TAPPING T2.5xL5 22-172-25005011 MYLAR-D8T0.3 30-056-02100378 Page: A-25 MH-5100 SERIES USER MANUAL...
  • Page 148: Exploded Diagram For Card Holder Assembly

    Appendix A System Diagrams Exploded Diagram For Card Holder Assembly Component Name P/N No. Q’ty CARD-LICENSE 30-002-28910378 VELCRO 30-082-31100378 CARD HOLDER 30-012-28510378 CARD HOLDER PLATE 80-005-03008378 FLAT HEAD SCREW#2/T3.0x6mm 22-112-30006011 Page: A-26 MH-5100 SERIES USER MANUAL...
  • Page 149: Appendix B Technical Summary

    Appendix B Technical Summary This appendix will give you a brief introduction of the allocation maps for MH-5100 resources. The following topics are included: • Interrupt Map • I/O Map • Memory Map • System BIOS Update Procedure Page: B-1 MH-5100 SERIES USER MANUAL...
  • Page 150: Interrupt Map

    Communications Port (COM1) IRQ 8 High precision event timer IRQ 9 GPIOVirtual Controller IRQ 24 Intel(R) SST Audio Device (WDM) IRQ 25 Intel(R) SST Audio Device (WDM) IRQ 26 Intel(R) SST Audio Device (WDM) IRQ 27 Intel(R) SST Audio Device (WDM)
  • Page 151 Microsoft ACPI-Compliant System IRQ 83 Microsoft ACPI-Compliant System IRQ 84 Microsoft ACPI-Compliant System IRQ 85 Microsoft ACPI-Compliant System Intel(R) Dynamic Platform & Thermal Framework Processor IRQ 86 Participant Driver IRQ 86 Microsoft ACPI-Compliant System IRQ 87 Microsoft ACPI-Compliant System Page: B-3...
  • Page 152 Appendix B Technical Summary Assignment IRQ 88 Microsoft ACPI-Compliant System IRQ 89 Microsoft ACPI-Compliant System IRQ 90 Microsoft ACPI-Compliant System IRQ 91 Microsoft ACPI-Compliant System IRQ 92 Microsoft ACPI-Compliant System IRQ 93 Microsoft ACPI-Compliant System IRQ 94 Microsoft ACPI-Compliant System IRQ 95 Microsoft ACPI-Compliant System IRQ 96...
  • Page 153 Appendix B Technical Summary Assignment IRQ 121 Microsoft ACPI-Compliant System IRQ 122 Microsoft ACPI-Compliant System IRQ 123 Microsoft ACPI-Compliant System IRQ 124 Microsoft ACPI-Compliant System IRQ 125 Microsoft ACPI-Compliant System IRQ 126 Microsoft ACPI-Compliant System IRQ 127 Microsoft ACPI-Compliant System IRQ 128 Microsoft ACPI-Compliant System IRQ 129...
  • Page 154 Appendix B Technical Summary Assignment IRQ 153 Microsoft ACPI-Compliant System IRQ 154 Microsoft ACPI-Compliant System IRQ 155 Microsoft ACPI-Compliant System IRQ 156 Microsoft ACPI-Compliant System IRQ 157 Microsoft ACPI-Compliant System IRQ 158 Microsoft ACPI-Compliant System IRQ 159 Microsoft ACPI-Compliant System IRQ 160 Microsoft ACPI-Compliant System IRQ 161...
  • Page 155 Appendix B Technical Summary Assignment IRQ 186 Microsoft ACPI-Compliant System IRQ 187 Microsoft ACPI-Compliant System IRQ 188 Microsoft ACPI-Compliant System IRQ 189 Microsoft ACPI-Compliant System IRQ 190 Microsoft ACPI-Compliant System IRQ 191 Microsoft ACPI-Compliant System IRQ 192 Microsoft ACPI-Compliant System IRQ 193 Microsoft ACPI-Compliant System IRQ 194...
  • Page 156 Appendix B Technical Summary Assignment IRQ 269 Microsoft ACPI-Compliant System IRQ 270 Microsoft ACPI-Compliant System IRQ 271 Microsoft ACPI-Compliant System IRQ 272 Microsoft ACPI-Compliant System IRQ 273 Microsoft ACPI-Compliant System IRQ 274 Microsoft ACPI-Compliant System IRQ 275 Microsoft ACPI-Compliant System IRQ 276 Microsoft ACPI-Compliant System IRQ 277...
  • Page 157 Appendix B Technical Summary Assignment IRQ 302 Microsoft ACPI-Compliant System IRQ 303 Microsoft ACPI-Compliant System IRQ 304 Microsoft ACPI-Compliant System IRQ 305 Microsoft ACPI-Compliant System IRQ 306 Microsoft ACPI-Compliant System IRQ 307 Microsoft ACPI-Compliant System IRQ 308 Microsoft ACPI-Compliant System IRQ 309 Microsoft ACPI-Compliant System IRQ 310...
  • Page 158 Appendix B Technical Summary Assignment IRQ 343 Microsoft ACPI-Compliant System IRQ 344 Microsoft ACPI-Compliant System IRQ 345 Microsoft ACPI-Compliant System IRQ 346 Microsoft ACPI-Compliant System IRQ 347 Microsoft ACPI-Compliant System IRQ 348 Microsoft ACPI-Compliant System IRQ 349 Microsoft ACPI-Compliant System IRQ 350 Microsoft ACPI-Compliant System IRQ 351...
  • Page 159 Appendix B Technical Summary Assignment IRQ 376 Microsoft ACPI-Compliant System IRQ 377 Microsoft ACPI-Compliant System IRQ 378 Microsoft ACPI-Compliant System IRQ 379 Microsoft ACPI-Compliant System IRQ 380 Microsoft ACPI-Compliant System IRQ 381 Microsoft ACPI-Compliant System IRQ 382 Microsoft ACPI-Compliant System IRQ 383 Microsoft ACPI-Compliant System IRQ 384...
  • Page 160 Appendix B Technical Summary Assignment IRQ 408 Microsoft ACPI-Compliant System IRQ 409 Microsoft ACPI-Compliant System IRQ 410 Microsoft ACPI-Compliant System IRQ 411 Microsoft ACPI-Compliant System IRQ 412 Microsoft ACPI-Compliant System IRQ 413 Microsoft ACPI-Compliant System IRQ 414 Microsoft ACPI-Compliant System IRQ 415 Microsoft ACPI-Compliant System IRQ 416...
  • Page 161 Appendix B Technical Summary Assignment IRQ 441 Microsoft ACPI-Compliant System IRQ 442 Microsoft ACPI-Compliant System IRQ 443 Microsoft ACPI-Compliant System IRQ 444 Microsoft ACPI-Compliant System IRQ 445 Microsoft ACPI-Compliant System IRQ 446 Microsoft ACPI-Compliant System IRQ 447 Microsoft ACPI-Compliant System IRQ 448 Microsoft ACPI-Compliant System IRQ 449...
  • Page 162 Appendix B Technical Summary Assignment IRQ 473 Microsoft ACPI-Compliant System IRQ 474 Microsoft ACPI-Compliant System IRQ 475 Microsoft ACPI-Compliant System IRQ 476 Microsoft ACPI-Compliant System IRQ 477 Microsoft ACPI-Compliant System IRQ 478 Microsoft ACPI-Compliant System IRQ 479 Microsoft ACPI-Compliant System IRQ 480 Microsoft ACPI-Compliant System IRQ 481...
  • Page 163 Intel(R) HD Graphics IRQ -3 Intel(R) Trusted Execution Engine Interface IRQ -2 Intel(R) USB 3.0 eXtensible Host Controller - 1.0 (Microsoft) Note: These resource information were gathered using Windows 10 (the IRQ could be assigned differently depending on OS). Page: B-15...
  • Page 164: I/O Map

    Appendix B Technical Summary I/O Map I/O Map Assignment 0x00000000-0x0000006F PCI Express Root Comple 0x00000020-0x00000021 Programmable interrupt controller 0x00000024-0x00000025 Programmable interrupt controller 0x00000028-0x00000029 Programmable interrupt controller 0x0000002C-0x0000002D Programmable interrupt controller 0x0000002E-0x0000002F Motherboard resources 0x00000030-0x00000031 Programmable interrupt controller 0x00000034-0x00000035 Programmable interrupt controller 0x00000038-0x00000039 Programmable interrupt controller 0x0000003C-0x0000003D...
  • Page 165 0x000000AC-0x000000AD Programmable interrupt controller 0x000000B0-0x000000B1 Programmable interrupt controller 0x000000B4-0x000000B5 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000004D0-0x000004D1 Programmable interrupt controller 0x000003F8-0x000003FF Communication Post(COM1) 0x00001000-0x00001007 Intel(R) HD Graphics 0x00000D00-0x0000FFFF PCI Express Root Complex Page: B-17 MH-5100 SERIES USER MANUAL...
  • Page 166: Memory Map

    Assignment 0x000A0000-0x000BFFFF PCI Express Root Complex 0x000C0000-0x000DFFFF PCI Express Root Complex 0x000E0000-0x000FFFFF PCI Express Root Complex 0x20000000-0x201FFFFF Intel(R) SST Audio Device (WDM) 0x7D000001-0x7F000000 PCI Express Root Complex 0x80000000-0x8FFFFFFF Intel(R) HD Graphics 0x80000000-0x908FFFFE PCI Express Root Complex 0x90000000-0x903FFFFF Intel(R) HD Graphics...
  • Page 167 Appendix B Technical Summary Memory Map Assignment Framework Processor Participant Driver 0xFED0C000-0xFED0CFFF GPIO Controller 0xFED0D000-0xFED0DFFF GPIO Controller 0xFED0E000-0xFED0EFFF GPIO Controller 0xFED40000-0xFED40FFF PCI Express Root Complex 0xFF000000-0xFFFFFFFF Legacy device Page: B-19 MH-5100 SERIES USER MANUAL...
  • Page 168: System Bios Update Procedure

    Appendix B Technical Summary System BIOS Update Procedure System BIOS Update from O.S. Prepare a bootable media (e.g. USB storage device) which can boot the system to UEFI32 prompt. Download and save the BIOS file (e.g. 51000PT6.exe) to the bootable device. Press the Power Button to boot up the system into the O.S.

Table of Contents
