CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier®
Introduction
1.5.7

Miscellaneous

Front panel
Loopbacks
Fault relays
M&C Interface
M&C Software
CDM-Qx
(70/140 MHz)
AC
Consumption
CDM-QxL
(L-band)
AC Operating Voltage
DC Operating Voltage
Operating
Temperature
Storage
Dimensions
Weight
1.5.8

Approvals

CE Mark
FCC
• Tactile keypad: 6 keys (Up/Down, Left/Right, Enter/Clear)
• VFD – Vacuum Fluorescent Display (blue): 2 lines of 40 characters each
Internal IF loopback, RF loopback, digital loopback, and inward/outward
loopback
Hardware fault, RX and TX Traffic Alarms
EIA-232 and EIA-485 (addressable multidrop, 2-wire or 4-wire), 10/100 BaseT
Ethernet
SATMAC software for control of local and distant units
120 watts (maximum)
250 watts (maximum)
100 to 240 VAC, +6%/-10% - autosensing
(total absolute max. range is 90 to 254 VAC)
36 to 72 VDC, 6.25 amps
o o
0 to 50 C (32 to 122 F)
o o
-25 to 85 C (-13 to 185 F)
1.75" H x 19" W x 19" D
(44 mm H x 480 mm W x 480 mm D)
< 20 lbs (7.0 kg) approx (depends on configuration)
EMC Safety
FCC Part 15 Class B
1–20
Revision 7
MN/CDMQx.IOM
