CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier®
Front Panel Operation
5.4.3.3 CONFIG: Rx
Rx Code Rate: 5/16 21/44 1/2
2/3 3/4 7/8 17/18 (◄ ►)
For the Receive Code Rate, select 5/16, 21/44, 1/2, 2/3, 3/4, 7/8, or 17/18 using the
keys, then press
Note the following:
CASE
5/16
21/44
1/2
2/3
3/4
7/8
17/18
All possible choices are presented at all times. If an option is not installed (either
Hardware, or FAST) or not valid, the ◄ ► arrow keys will force the cursor to
skip past the unavailable choice.
5.4.3.4 CONFIG: Rx
Rx Data Rate: 05000.000kbps
Sym:02500.000ksps
Note: In Quad Drop & Insert (QDI) mode, these data rates are read-only! The data rate will be
the sum of the tributary rates for all ports. This also will show the calculated symbol rate and
Nx64kbps (where N=001 to 128).
The overall range of data rates is from 32 to 20000 kbps. The overall range of
symbol rates is up to 10000 ksps. The minimum data rate is set to 32 kbps only
for BPSK and QPSK, and the maximum data rates are dependent on modulation
IMPORTANT
type and FEC encoder rate. If the user changes the modulation or FEC, and the
currently selected data rate can no longer be supported, the data rate will be
adjusted automatically, up or down,
bottom line of the display shows the symbol rate, based on FEC type,
modulation, FEC Code Rate, and Data Rate. The valid ranges of data rate are
shown in the table that follows on the next page.
Code
.
ENTER
RULES
Valid for BPSK and Turbo
Valid for BPSK, QPSK and Turbo
Valid for BPSK, QPSK, Viterbi, Viterbi+R-S
Valid for TCM+R-S only (8-PSK)
Valid for QPSK, 8-PSK, and 16-QAM
Valid for QPSK, 8-PSK, and 16-QAM
Valid for QPSK, 8-PSK , and Turbo
Data
keeping the symbol rate constant. The
5–23
Revision 7
MN/CDMQX.IOM
arrow
◄ ►
