CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier®
Front Panel Operation
5.5.4.2 MONITOR: Stats
Clear All Stored Stats?
No Yes
When selected, and in Local mode, the user is prompted to answer No to retain the stored link
statistics, or Yes to clear the buffer of all stored link statistics. Select the choice using the ◄ ►
arrow keys, then press
Note: When the unit is in Remote mode, and the Clear-All menu is selected, the following message
is displayed:
THIS UNIT IS CURRENTLY
When the link statistics log is cleared, the user is returned to the previous menu.
5.5.4.3 MONITOR: Stats
Stats Logging Interval:
30 minutes
Select a logging interval for the link statistics (i.e., the period of time, in minutes, for which
statistics will be measured) using the
selections are Disabled, 10, 20, 30, 40, 50, 60, 70, 80, or 90.
5.5.5

MONITOR: AUPC

• This read-only screen is operable only for a modulator/demodulator pair
grouped as a 'modem'.
• Framing mode must be active in order for correct viewing of this screen.
IMPORTANT
If MONITOR: AUPC is selected, and the modem is not in Framed mode, the
following message displays:
Press ENTER or CLEAR to return to the previous menu, then, via the CONFIG:
Frame menus, configure the modem as needed for Framing mode.
Once configured for Framed mode, when MONITOR: AUPC is selected, the
proper read-only screen should display:
Per this example:
•
The top line displays the value of Eb/No of the demodulator at the distant end of the
satellite link. The Eb/No displays Unlock if the remote demod is unlocked.
•
The bottom line shows how much the AUPC system has increased the output power. If
AUPC is not enabled, the value of Tx Power Increase will show as 0.0 dB.
Clear-All
.
ENTER
IN REMOTE MODE!!
Config
(◄ ►,ENT)
Framing is required for
AUPC Monitor
AUPC:Remote EbNo
TX Power Increase =
(◄ ►,ENT)
arrow keys, then press
(ENT or CLR)
= 14.0dB
2.2dB
5–47
Revision 7
MN/CDMQX.IOM
. The available
ENTER
