Comtech EF Data CDM-Qx Installation And Operation Manual page 101

CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier®
Front Panel Operation
5.4.6.4 CONFIG: Interface
QDI Tributary Ports
1 2
Select 1, 2, 3, or 4 using the ◄ ► arrow keys, then press
CONFIG: Interface
Port#X: Drop Insert LineCode
Where X is the selected tributary port number for this menu and all submenus that follow: Select
Drop, Insert, LineCode, or Alarm using the ◄ ► arrow keys, then press
CONFIG: Interface
Port#X Tx Trib Rate:(▲ ▼ ENT)
Disabled
Set the desired Drop / Tx Tributary data rate by using the
when done. Note that this example depicts the Nx64kbps data rate where N=0 (Disabled).
The next example depicts the Nx64kbps data rate where N=24:
Port#X Tx Trib Rate:(▲ ▼ ENT)
01536.000kbps
To continue, the next example depicts the Nx64kbps data rate where N=32 (Full E1) is
specified:
Port#X Tx Trib Rate:(▲ ▼ ENT)
Full E1
When N=32 (Full E1) is selected, pressing
menu. Otherwise, the following submenu displays (where X is the selected tributary port
number):
PX D-CH: 1
When
beyond Channel 6. Use right arrow key
pressed once the selection is made.
CONFIG: Interface
Port#X Rx Trib Rate:(▲ ▼ ENT)
01536.000kbps
Similar to the Drop side, set the desired Insert / Rx Tributary Data Rate by using the
arrow keys. Press
rate where N=24. Once a data rate has been set, the following submenu displays (where X
is the selected tributary port number):
PX I-CH: 1
QDI
3 4 (◄ ►,ENT)
QDI
Alarm
QDI
2 3
TS: 11 02 06 04 05 03
displays, as per this example, this means that there are more channels available
QDI
when done. Note that this example depicts the Nx64kbps data
ENTER
2 3
TS: 11 02 06 04 05 03
.
ENTER
1, 2, 3, or 4
(◄ ► ENT)
1, 2, 3, or 4
(00x64kbps)
(24x64kbps)
(32x64kbps)
takes the user back to the QDI parent
ENTER
4 5 6 ►
to view more, making sure that
1, 2, 3, or 4
(24x64kbps)
4 5 6 ►
5–35
Revision 7
MN/CDMQX.IOM
.
ENTER
Drop
arrow keys. Press
ENTER
ENTER
Insert
is
