Table 5-1. Prinicpal Menu Tree - Comtech EF Data CDM-Qx Installation And Operation Manual

CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier®
Front Panel Operation
Section Title
5.2 Opening Screen
5.3 Main Menu
5.4 Config
Config → Remote
5.4.1
Config → Tx
5.4.2
5.4.3 Config → Rx
Config → Group
5.4.4
5.4.5 Config → Frame
Config → Interface
5.4.6
Config → Ref
5.4.7
5.4.8 Config → Mask
Config → ODU
5.4.9
(CDM-QxL only)
5.5 Monitor
5.5.1 Monitor → Alarms
Monitor → Rx-Params
5.5.2
Monitor → Event-Log
5.5.3
5.5.4 Monitor → Stats
Monitor → AUPC
5.5.5
(CDM-QxL only)
Monitor → CnC
5.5.6
Monitor → ODU
5.5.7
(CDM-QxL only)
5.6 Test
Test → Mode
5.6.1
5.6.2 Test
5.6.3 Test
5.7 Info
5.8 Save/Load
5.9 Utility
5.9.1 Utility
5.9.2 Utility
5.9.3 Utility
5.9.4 Utility
5.9.5 Utility
5.9.6 Utility
5.9.7 Utility
For the purpose of clarity, only the right-hand display area (or menu screen) is visually depicted
throughout the remainder of this chapter.

Table 5-1. Prinicpal Menu Tree

Remarks
Select: Config; Monitor; Test; Info; Save/Load; Utiity
Select: Remote; Tx; Rx; Group; Frame; Interface; Ref; Mask; (CDM-QxL only) ODU
Select: Local; Serial; Ethernet
Select: FEC; Mod; Code; Data; Freq; On/Off; Pwr; Scram; Clk; Inv; Txα
Select: FEC; Demod; Code; Data; Freq; Acq; Descram; Buf; Inv; Misc; CNC
Select: Modem; Redundancy
Select: Unframed; EDMAC; EDMAC-2; D&I++
Select: RS422; V.35; RS232; HSSI; G.703; QDI; None
Select: Internal; 10MHz
Select: Transmit; Receive; Reference; (CDM-QxL only) BUC; (CDM-QxL only) LNB
Select: BUC; LNB
Select: Alarms; Rx-Params; Event-Log; Stats; AUPC; CNC; (CDM-QxL only) ODU
Select: Transmit; Receive; Unit; (CDM-QxL only) ODU
Select: Eb/No, BER, ΔF, BUF, RSL
Select: View; Clear-All
Select: View; Clear-All; Config
Framing is required for AUPC Monitor - Select: Remote Eb/No; Tx Power Increase
Carrier in Carrier® (CnC) indicates as Active or N ot Active
Select: ODU; LNB
Select: Mode; BIST; Spec-Analyzer
Select: Norm; IF Loop; Dig Loop; I/O Loop; RF Loop; Tx-CW; Tx-1,0
BIST Select: BERT-Config; BERT-Mon; BERT-Control
Spec-Analyzer Select: Center-Freq; Span
Select: Rem; Tx; Rx; Buffer; Frame; Interface; Mask; Ref; ID
Select: Save; Load
Select: RxBuffer; Clock; Ref; ID; Display; Firmware; FAST
RxBuffer Select to Re-center buffer
Clock Select to edit Real-Time Clock (Time and Date)
Ref Select: Adjust; Warm-up Delay
ID Select to edit Circuit ID
Display Select to adjust VFD brightness
Firmware Select: Update-CPLD; Information; Select
FAST Select: Base; Slot1; Slot2; Slot3; Slot4
