CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier®
Front Panel Operation
5.9.7

UTILITY: FAST

FAST – Select the module:
Base Slot1 Slot2 Slot3 Slot4
FAST (Fully Accessible System Topology) is used to enable new options in the CDM-Qx/QxL.
Contact Comtech EF Data to obtain the FAST code for the desired option. For a step-by-step
tutorial on this complete upgrade process, refer to Appendix B. FAST ACTIVATION
PROCEDURE.
◄ ►
Using the
done. Note the following:
•
Base refers to the base unit, where the redundancy and CnC options may be viewed.
•
Slot# refers to the four module slots available in the rear panel of the chassis.
UTILITY: FAST
FAST: Config
Board S/N: 123456789
The Base unit screen displays the chassis hardware version and the motherboard serial number. This
information will be needed when contacting Comtech EF Data Technical Support to obtain the FAST
code needed for upgrade. Select Config or View using the
UTILITY: FAST
FAST Configuration:
Edit Code
Select Edit Code or Demo Mode using the
UTILITY: FAST
Edit 20 digit FAST Code:
00000000000000000000
The Edit Code screen is used to enable new options in the modem. Once the FAST code
for the new option has been obtained from Comtech EF Data, enter the code carefully.
Use the
keys to edit the character. When all characters are edited, press
The modem will respond with "Configured Successfully" if the new FAST
option has been accepted; otherwise, you may return to the menu to edit futher.
UTILITY: FAST
FAST Demo Mode: Off
Select Off or On using the
Mode allows access to ALL CDM-Qx/QxL FAST options for 3,888,000 seconds (45 full
days). Demo Mode may be turned on and off an unlimited number of time until all
3,888,000 seconds have expired; the time count only decrements when the mode is On.
arrow keys, select Base, Slot1, Slot2, Slot 3, or Slot 4, then press
Base
View (HW 1.02)
Base
Demo Mode
Base
◄ ►
arrow keys to move the cursor to each character, then use the
Base
604,800 seconds remaining
◄ ►
(Base)
◄ ►
arrow keys, then press
Config
◄ ►
arrow keys, then press
Edit Code
(ENT)
Demo Mode
On
arrow keys, then press
5–62
Revision 7
MN/CDMQX.IOM
ENTER
ENTER
.
ENTER
▲ ▼
.
ENTER
When enabled, Demo
ENTER.
when
.
arrow
