CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier®
Ethernet Management

6.5.3 User Login

To initiate a Web session with the CDM-Qx/QxL Modem, from the PC type
http://www.xxx.yyy.zzzz (where "www.xxx.yyy.zzz" represents the IP address of the CDM-Qx/QxL
Multi-Channel Satellite Modem) into the Address area of the Web browser:
The Login window will appear, and the user is prompted to type a User Name and Password.
HTTP Login Access Levels are defined as follows:
User Interface
Web
CDM-Qx/QxL Satellite Modem Web Server Default
Name/Passwords are:
Admin
Read/Write
Read Only
Type the User Name and Password, then click [OK].
Once the valid User Name and Password is accepted, the user will see the CDM-Qx/QxL Multi-
Channel Satellite Modem Web Server Interface "splash" page (right). From this top level menu,
depending on the unit in use the user has access to four or five navigation tabs:
•
Home
•
Admin (Administration)
•
Config (Configuration)
•
ODU (Outdoor Unit)*
•
Maint (Maintenance).
* CDM-QxL only.
Click any tab to continue.
Admin User Read/Write User
No Access to Admin or
Encryption Web pages
Full Access to
all Web Pages
Full Access for all other
Web Pages
comtech/comtech
opcenter/1234
monitor/1234
User Login Access Level
No Access to Admin or Encryption
Web pages
View Only Access for all other Web
Pages
6–7
Revision 7
MN/CDMQX.IOM
Read Only User
