CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier®
Front Panel Operation
UTILITY: Firmware
Image#x: Bulk Firmware
FW/00107E
For either Image#1 or Image#2: Use the
screen for each component of the firmware image.
Examples:
Image#x: App Firmware
FW/00109E
Image#x: Mod FPGA
FW/11251G
Press or
ENTER
UTILITY: Firmware
CPLD Info:
FW/11255
Firmware versions for both the Modulator and Demodulator modules are shown, as per the above
example. Press
5.9.6.3 UTILITY: Firmware
Current Active Image: #1
Next Reboot Image: #1 #2
The top line shows the current active boot image. Using the
user may select #1 or #2 as the image that will be active the next time the unit is rebooted. Press
when done.
ENTER
Information
05/20/09
05/20/09
06/05/08
to return to the previous menu.
CLEAR
Information
Tx=1.2.4
or to return to the previous menu.
ENTER CLEAR
Select
Image#1, Image#2
(▲ ▼)
2.1.5
arrow keys to browse through each read-only
(▲ ▼)
2.1.5
(▲ ▼)
1.1.8
CPLD
Rx=1.2.4
◄ ► arrow keys, on the bottom line, the
5–61
Revision 7
MN/CDMQX.IOM
