Comtech EF Data CDM-Qx Installation And Operation Manual page 225

CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier®
Appendix C
C.6.1 Transmit (Tx) Commands and Queries
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier) to Query
Tx Data TCI= 1 byte, value
Clock Invert 0,1
TX Clock TCK= 1 byte, value 0
Source 1, 2
TX FEC TCR= 1 byte, value
Code Rate of 0 though 7
TX Data TDI= 1 byte, value
Invert 0,1
Description of Arguments
Command or Query.
Invert Transmit Data Clock in the form x, where:
0=Normal
1=Inverted
Command or Query.
TX Clock Source in the form x, where:
0=Internal
1=TX Terrestrial
2=Loop-Timed
3=Ext loop (G.703 interface only)
Example: TCK=0 (Internal)
Command or Query.
TX Code Rate in the form x, where:
0=Rate 5/16 (Turbo only)
1=Rate21/44 (Turbo only)
2=Rate 1/2
3=Rate 2/3 (8-PSK, TCM+RS only)
4=Rate3/4
5=Rate7/8
6=Rate 17/18 (Turbo only)
7=Reserved
Depending on FEC and Modulation Type, not all of these
selections will be valid.
Example: TCR=4 (Rate 3/4)
Command or Query.
Invert Transmit Data in the form x, where:
0=Normal
1=Inverted
Example: TDI=1(Inverted TX Data)
Response to
Command
TCI=
TCI?
TCI*
TCI#
TCI$
TCI^
TCI@
TCK=
TCK?
TCK*
TCK#
TCK$
TCK^
TCK@
TCR=
TCR?
TCR*
TCR#
TCR$
TCR^
TCR@
TDI=
TDI?
TDI*
TDI#
TDI$
TDI^
TDI@
C–7
Revision 7
MN/CDMQX.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
TCI? TCI=x
(see Description of
Arguments)
TCK? TCK=x
(see Description of
Arguments)
TCR? TCR=x
(see Description of
Arguments)
TDI? TDI=x
(see Description of
Arguments)
