CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier®
Installation
Support Bracket
#10 Bracket Bolt

Figure 2-1. Installation of Optional Rear-Mounting Support Brackets

#10 Shoulder Screw
#10 Flat Washer
#10 Flat Washer
#10 Split Washer
#10 Hex Nut
Equipment Rack
Rear Mounting Rail
Back of unit
2–3
Revision 7
MN/CDMQX.IOM
