Base Chassis Connections

3.2.1

Power Connector

For continued operator safety, always replace the fuses with the correct type
and rating.
IMPORTANT
3.2.1.1

AC Power Connector

3.2.1.2

DC Power Supply (CDM-QxL, Optional)

3.2.2

Ground Connector

A #10-32 stud, located adjacent to the power connection on the rear panel of the
modem, is used for connecting a common chassis ground among equipment.
Note: The AC power connector provides the safety ground.
A standard, detachable, non-locking, 3-prong power cord (IEC plug) supplies
the Alternating Current (AC) power to the modem. Observe the following:
Input Power
Input Voltage
Connector Type
Fuse Protection
A standard, 3-screw terminal block supplies the Direct Current (DC) power to
the modem. Observe the following:
Input Power 250W maximum, 110W typical without BUC power supply.
Input Voltage 36 to 72 VDC; 6.25 amps
Connector Type Terminal Block
Fuse Protection 6.25A Slow-blow
With 24 VDC BUC:
With 48 VDC BUC:
3–4
AC Power Specifications
290W maximum, 110W typical without BUC power supply.
100 - 240 volts AC, +6/-10% - autosensing
(total absolute max. range is 90 to 254 VAC)
IEC
CDM-Qx (70/140): 2.0A Slow-blow
Line and neutral fusing
20 mm type fuses
CDM-QxL (L-Band): 3.15A Slow-blow
Line and neutral fusing
20 mm type fuses
DC Power Specifications
TBD
TBD
