Config Mdm | Quick View | Test; Figure 6-12. 'Config Mdm | Quick View | Test' Nested Pages – Base, Tx - Comtech EF Data CDM-Qx Installation And Operation Manual

CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier®
Ethernet Management
6.5.4.3.1.3 Config Mdm | Quick View | Test Pages
Depending on the configuration icon selected, the nested Test page provides the user with access
to demodulator module constellation displays and the Spectrum Analyzer feature, and an
assortment of modem test functions. For detailed information on these features, refer to Sect. 5.6
(MAIN MENU:) TEST in Chapter 5. FRONT PANEL OPERATION.
Figure 6-12. 'Config Mdm | Quick View | Test' Nested Pages – Base, Tx
Test Page – 'Base' Selected (Quad Demod Configuration)
Test Page – 'Tx' Selected (Independent Tx/Rx Configuration)
