CDM-Qx/QxL Multi-Channel Satellite Modem with DoubleTalk™ Carrier-in-Carrier®
Front Panel Operation
Load Config from Location 9
Empty
Locations 1 through 10 are available. Using the
to load a configuration, then press ENTER. If the selected location contains valid data, the
following screen is displayed:
New Config has been Loaded
from Location 9
Press or
ENTER
valid data, the following screen is displayed:
Warning! Location 9
Contains No Data!
Press or
ENTER
5.9

(MAIN MENU:) Utility

UTILITY: RxBuffer Clock Ref
ID Display
Select RxBuffer, Clock, Ref, ID, Display, Firmware or FAST using the ◄ ► arrow keys then
press .
ENTER
5.9.1

UTILITY: RxBuffer

Press ENT to Re-Center
the Receive Buffer
Press to cause a forced re-centering of the Plesiochronous/Doppler Buffer.
ENTER
5.9.2

UTILITY: Clock

Real-Time Clock:(◄ ►,▲ ▼,ENT)
Time=12:00:00
To edit the Real-Time Clock time and date settings, first select the digit to be
edited using the
arrow keys. Press ENTER when done.
IMPORTANT
Note that, in accordance with international convention, the date is shown in
DAY-MONTH-YEAR format.
(▲ ▼ ENT)
(ENT)
to return to the previous menu. If the selected location does not contain
CLEAR
(ENT)
to return to the previous menu.
CLEAR
Firmware
Date:24/04/03
arrow keys, then change the value of that digit using the
arrow keys, select the location from which
FAST
5–58
Revision 7
MN/CDMQX.IOM
