5.1

Front Panel Overview

USB
Port
The user can fully control and monitor the operation of the CDM-Qx/QxL from the front panel
using the keypad and display. Nested menus are used, which display all available options and
prompt the user to carry out a required action.
Figure 5-1 identifies the key features of the front panel, which are explained in greater detail in
the sections that follow.
5.1.1

USB Port

This USB Slave connector allows the user to reflash firmware. See Chapter 4. FLASH
UPGRADING for complete information about firmware upgrade procedures for the
CDM-Qx/QxL.
Chapter 5. FRONT PANEL
LED Indicators Keypad
Figure 5-1. CDM-Qx/QxL – Front Panel View
OPERATION
VFD Left-Hand
Display Area
5–1
VFD Right-Hand
Display Area
