Configuring the Communication Mode Manually

This topic gives instructions for configuring the communication mode manually.
1.
Press the Menu button to display MAIN MENU.
2.
Press ▲ or ▼ to select Interface Setup, and then press the ▶ button.
3.
Press ▲ or ▼ to select Ethernet Driver, and then press the ▶ button.
4.
Press ▲ or ▼ to select Auto Detect, and then press the ▶ button.
5.
Press ▲ or ▼ to select Off, and then press the OK button.
Return to the Ethernet Driver menu.
6.
Press ▲ or ▼ to select Comm.Mode, and then press the ▶ button.
7.
Press ▲ or ▼ to select the communication mode, and then press the OK button.
10
Return to the Ethernet Driver menu.
8.
Press ▲ or ▼ to select Ethernet Type, and then press the ▶ button.
9.
Press ▲ or ▼ to select the Ethernet type, and then press the OK button.
Return to the Ethernet Driver menu.
10.
Press ▲ or ▼ to select Spanning Tree, and then press the ▶ button.
11.
Press ▲ or ▼ to enable or disable spanning tree support, and then press the OK button.
Return to the Ethernet Driver menu.
