Printer Parts > Optional accessories
13.
Unlock the flange on the left side of the Rewind Spool by lifting the lever (a) from the shaft side. Remove the
flange.
14.
Remove the entire paper core with the rewound printed documents from the Rewind Spool.
9
764
Removing Printed Documents from the Media Take-up Unit
>
Important
• Always turn off the Media Take-up Unit before removing the Rewind Spool. The Media Take-up
Unit may be damaged if you do not turn it off first.
• Remove the Rewind Spool, pulling off both ends from the Media Take-up Unit at once.
Note
• You can leave the Rewind Spool on the Media Take-up Unit even when it is not used for rewinding
rolls.
iPF815
