Output Method; Size Options - Canon imagePROGRAF iPF815 User Manual

Windows Software
• Making the Original Orientation Match the Paper Orientation
K
Rotate Page 90 degrees (Conserve Paper)
Activate this setting to rotate the document image by 90 degrees before printing.
• Conserving Roll Paper by Rotating Originals 90 Degrees
L
Paper Source
Choose the feed source, as desired.
Options displayed in the list vary depending on the selection in Media Type on the Main sheet.
M
Roll Paper Width
Choose the roll width.
For details on available roll widths, see " Paper Sizes
N
Roll Paper Options
4
Complete optional roll paper settings. Click to display the Roll Paper Options dialog box.
A
Under Automatic Cutting, you can specify Yes or No and Print Cut Guideline.
• Cutting Roll Paper After Printing
B
Select Banner Printing when printing multiple pages continuously.
• Printing Multiple Pages Continuously
P

Output Method

Click to display the Output Method dialog box, which enables you to complete the Output Method and Name of data to
be saved settings.
• Output Method dialog box
O

Size Options

Click to display the Paper Size Options dialog box, which enables you to register additional paper sizes or select the size
230
system for use.
• Paper Size Options Dialog Box
S
Defaults
Restores all settings on the sheet to the default values.
Page Setup Sheet
> Printer Driver >
→P.196
→P.138
→P.231
→P.232
→P.190
→P.167
"
→P.620
iPF815
