32581C
Table 4-2. Multiplexing, Interrupt Selection, and Base Address Registers (Continued)
Bit
Description
12
TRDESEL (Select TRDE#). Selects ball function.
Ball #
H1 / D11
11
EIDE (Enable IDE Outputs). This bit enables IDE output signals.
0: IDE signals are HiZ. Other signals multiplexed on the same balls are HiZ until this bit is set. (without regard to bit 24 of
this register). This bit does not control IDE channel 1 control signals selected by bit 8 of this register.
1:
Signals are enabled.
10
ETFT (Enable TFT Outputs). This bit enables TFT output signals, that are multiplexed with the Parallel Port and controlled
by PMR[23].
0: Signals TFTD[17:0], TFTDE and TFTDCK are set to 0.
1: Signals TFTD[17:0], TFTDE and TFTDCK are enabled.
Note:
TFTDCK that is multiplexed on IDE_RST# (ball AA1) is also enabled by this bit.
9
IOCHRDY (Select IOCHRDY). Selects ball function.
Ball #
H4 / C9
8
IDE1SEL (Select IDE Channel 1). Selects IDE Channel 1 or GPIO ball functions. Works in conjunction with PMR[18] and
PMR[17], see PMR[18] and PMR[17] for definitions.
7
DOCCSSEL (Select DOCCS#). Selects DOCCS# or GPIO20 ball functions. Works in conjunction with PMR[23], see
PMR[23] for definition.
6
SP3SEL (Select UART3). Selects ball functions.
Ball #
J28 / AK8
J3 / C11
5
IOCS0SEL (Select IOCS0#). Selects ball function. Works in conjunction with PMR[23], see PMR[23] for definition.
4
INTCSEL (Select INTC#). Selects ball function. Works in conjunction with PMR[9], see PMR[9] for definition.
3
Reserved. Write as read.
2
DOCWRSEL (Select DiskOnChip and NAND Flash Command Lines). Selects ball functions. Works in conjunction with
PMR[21], see PMR[21] for definition.
1
Reserved. Write as read.
0
PCBEEPSEL (Select PC_BEEP). Selects ball function.
Ball #
AL15 / V31
Offset 34h-37h
Power-on reset value: The BOOT16 strap pin selects "Enable 16-Bit Wide Boot Memory".
31
DID0 (Ball C5) Strap Status. (Read Only) Represents the value of the strap that is latched after power-on reset. Read in
conjunction with bit 29.
30
FPCI_MON (Ball A4) Strap Status. (Read Only) Represents the value of the strap that is latched after power-on reset.
Indicates if Fast-PCI monitoring output signals (instead of Parallel Port and some audio signals) are enabled. The state of
this bit along with PMR[27] control the Fast-PCI monitoring function. See PMR[27] definition.
29
DID1 (Ball C6) Strap Status. (Read Only) Represents the value of the strap that is latched after power-on reset. Read in
conjunction with bit 31.
28:20
Reserved.
19:18
Reserved. Write as 0.
17
HSYNC Timing. HSYNC timing control for TFT.
0: Reserved.
1: HSYNC timing suited for TFT.
74
0: Sub-ISA Signal
Name
Add'l Dependencies
TRDE#
None
0: PCI, GPIO Signal
Name
Add'l Dependencies
GPIO19
PMR[4] = 0
INTC#
PMR[4] = 1
0: IR Signals
Name
Add'l Dependencies
IRRX1
None
IRTX
None
0: GPIO Signal
Name
Add'l Dependencies
GPIO16
FPCI_MON = 0
F_DEVSEL#
FPCI_MON = 1
Miscellaneous Configuration Register - MCR (R/W)
General Configuration Block
1: GPIO Signal
Name
Add'l Dependencies
GPIO0
None
1: Sub-ISA Signal
Name
Add'l Dependencies
IOCHRDY
PMR[4] = 1
Undefined
PMR[4] = 0
1: Serial Port Signals
Name
Add'l Dependencies
SIN3
None
SOUT3
None
1: Audio Signal
Name
Add'l Dependencies
PC_BEEP
FPCI_MON] = 0
F_DEVSEL#
FPCI_MON = 1
Reset Value: 0000001h
AMD Geode™ SC3200 Processor Data Book
