Core Logic Module - Bridge, GPIO, and LPC Registers - Function 0
Table 6-29. F0: PCI Header/Bridge Configuration Registers for GPIO and LPC Support (Continued)
Bit
Description
Index 40h
7:6
Reserved. Must be set to 0.
5
Reserved. Must be set to 0.
4
PCI Subtractive Decode.
0: Disable transfer of subtractive decode address to external PCI bus. External PCI bus is not usable.
1: Enable transfer of subtractive decode address to external PCI bus. Recommended setting.
3
Reserved. Must be set to 1.
2
Reserved. Must be set to 0.
1
PERR# Signals SERR#. Assert SERR# when PERR# is asserted or detected as active by the Core Logic module (allows
PERR# assertion to be cascaded to NMI (SMI) generation in the system).
0: Disable.
1: Enable.
0
PCI Interrupt Acknowledge Cycle Response. The Core Logic module responds to PCI interrupt acknowledge cycles.
0: Disable.
1: Enable.
Index 41h
7:6
Reserved. Must be set to 0.
5
X-Bus Configuration Trap. If this bit is set to 1 and an access occurs to one of the configuration registers in PCI Function
5 (F5) register space, an SMI is generated. Writes are trapped; access to the register is denied. Reads are snooped; access
to the register is allowed.
0: Disable.
1: Enable.
Top level SMI status is reported at F1BAR0+I/O Offset 00h/02h[9].
Second level SMI status is reported at F1BAR0+I/O Offset 04h/06h[5].
4
Video Configuration Trap. If this bit is set to 1 and an access occurs to one of the configuration registers in PCI Function 4
(F4) register space, an SMI is generated. Writes are trapped; access to the register is denied. Reads are snooped; access
to the register is allowed.
0: Disable.
1: Enable.
Top level SMI status is reported at F1BAR0+I/O Offset 00h/02h[9].
Second level SMI status is reported at F1BAR0+I/O Offset 04h/06h[5].
3
Audio Configuration Trap. If this bit is set to 1 and an access occurs to one of the configuration registers in PCI Function
3 (F3) register space, an SMI is generated. Writes are trapped; access to the register is denied. Reads are snooped; access
to the register is allowed.
0: Disable.
1: Enable.
Top level SMI status is reported at F1BAR0+I/O Offset 00h/02h[9].
Second level SMI status is reported at F1BAR0+I/O Offset 04h/06h[5].
2
IDE Configuration Trap. If this bit is set to 1 and an access occurs to one of the configuration registers in PCI Function 2
(F2) register space, an SMI is generated. Writes are trapped; access to the register is denied. Reads are snooped; access
to the register is allowed.
0: Disable.
1: Enable.
Top level SMI status is reported at F1BAR0+I/O Offset 00h/02h[9].
Second level SMI status is reported at F1BAR0+I/O Offset 04h/06h[5].
AMD Geode™ SC3200 Processor Data Book
PCI Function Control Register 1 (R/W)
PCI Function Control Register 2 (R/W)
32581C
Reset Value: 39h
Reset Value: 00h
191
