5.4.2.6 LDN 07h - Parallel Port
The Parallel Port supports all IEEE 1284 standard commu-
nication modes: Compatibility (known also as Standard or
SPP), Bidirectional (known also as PS/2), FIFO, EPP
(known also as Mode 4) and ECP (with an optional
Extended ECP mode).
The Parallel Port includes two groups of runtime registers,
as follows:
• A group of 21 registers at first level offset, sharing 14
entries. Three of these registers (at Offset 403h, 404h,
and 405h) are used only in the Extended ECP mode.
Index Type Configuration Register or Action
30h R/W Activate. See also bit 0 of the SIOCF1 register.
60h R/W Base Address MSB register. Bits [7:3] (for A[15:11]) are RO, 00000b. Bit 2 (for A10)
should be 0b.
61h R/W Base Address LSB register. Bits 1 and 0 (A1 and A0) are RO, 00b. For ECP Mode 4
(EPP) or when using the Extended registers, bit 2 (A2) should also be 0b.
70h R/W Interrupt Number.
71h R/W Interrupt Type.
Bits [7:2] are RO.
Bit 1 is R/W.
Bit 0 is RO. It reflects the interrupt type dictated by the Parallel Port operation mode.
This bit is set to 1 (level interrupt) in Extended Mode and cleared (edge interrupt) in all
other modes.
74h R/W DMA Channel Select.
75h RO Report no second DMA assignment.
F0h R/W Parallel Port Configuration register. (See Table 5-16.)
Bit Description
Index F0h
This register is reset by hardware to F2h.
7:5 Reserved. Must be 11.
4 Extended Register Access.
0: Registers at base (address)+403h, base+404h and base+405h are not accessible (reads and writes are ignored).
1: Registers at base (address)+403h, base+404h and base+405h are accessible. This option supports run-time configura-
tion within the Parallel Port address space.
3:2 Reserved.
1 Power Mode Control. When the logical device is active:
0: Parallel port clock disabled. ECP modes and EPP timeout are not functional when the logical device is active. Registers
are maintained.
1: Parallel port clock enabled. All operation modes are functional when the logical device is active. (Default)
0 TRI-STATE Control. When enabled and the device is inactive, the logical device output pins are in TRI-STATE.
0: Disable. (Default)
1: Enable.
102

Table 5-15. Relevant Parallel Port Registers

Table 5-16. Parallel Port Configuration Register

Parallel Port Configuration Register (R/W)
• A group of four registers, used only in the Extended ECP
mode, accessed by a second level offset.
The desired mode is selected by the ECR runtime register
(Offset 402h). The selected mode determines which runt-
ime registers are used and which address bits are used for
the base address. (See Section 5.8.1 on page 127 for fur-
ther details regarding the runtime registers.)
Table 5-15 lists the configuration registers which affect the
Parallel Port. Only the last register (F0h) is described here
(Table 5-16). See Table 5-3 "Standard Configuration Regis-
ters" on page 93 for descriptions of the others.
AMD Geode™ SC3200 Processor Data Book
SuperI/O Module
Reset
Value
00h
02h
78h
07h
02h
04h
04h
F2h
Reset Value: F2h
