6.3.2
Register Summary
The tables in this subsection summarize the registers of
the Core Logic module. Included in the tables are the regis-
ter's reset values and page references where the bit for-
mats are found.
Table 6-14. F0: PCI Header/Bridge Configuration Registers
Width
F0 Index
(Bits)
Type
00h-01h
16
RO
02h-03h
16
RO
04h-05h
16
R/W
06h-07h
16
R/W
08h
8
RO
09h-0Bh
24
RO
0Ch
8
R/W
0Dh
8
R/W
0Eh
8
RO
0Fh
8
RO
10h-13h
32
R/W
14h-17h
32
R/W
18h-2Bh
---
---
2Ch-2Dh
16
RO
2Eh-2Fh
16
RO
30h-3Fh
---
---
40h
8
R/W
41h
8
R/W
42h
---
---
43h
8
R/W
44h
8
R/W
45h
---
---
46h
8
R/W
47h
8
R/W
48h-4Bh
---
---
4Ch-4Fh
32
R/W
50h
8
R/W
51h
8
R/W
52h
8
R/W
53h
8
R/W
54h-59h
---
---
5Ah
8
R/W
5Bh
8
R/W
5Ch
8
R/W
5Dh
8
R/W
5Eh-5Fh
---
---
60h-63h
32
R/W
64h-6Bh
---
---
174
for GPIO and LPC Support Summary
Name
Vendor Identification Register
Device Identification Register
PCI Command Register
PCI Status Register
Device Revision ID Register
PCI Class Code Register
PCI Cache Line Size Register
PCI Latency Timer Register
PCI Header Type Register
PCI BIST Register
Base Address Register 0 (F0BAR0) — Sets the base address for
the I/O mapped GPIO Runtime and Configuration Registers (sum-
marized in Table 6-15).
Base Address Register 1 (F0BAR1) — Sets the base address for
the I/O mapped LPC Configuration Registers (summarized in
Table 6-16)
Reserved
Subsystem Vendor ID
Subsystem ID
Reserved
PCI Function Control Register 1
PCI Function Control Register 2
Reserved
PIT Delayed Transactions Register
Reset Control Register
Reserved
PCI Functions Enable Register
Miscellaneous Enable Register
Reserved
Top of System Memory
PIT Control/ISA CLK Divider
ISA I/O Recovery Control Register
ROM/AT Logic Control Register
Alternate CPU Support Register
Reserved
Decode Control Register 1
Decode Control Register 2
PCI Interrupt Steering Register 1
PCI Interrupt Steering Register 2
Reserved
ACPI Control Register
Reserved
Core Logic Module - Register Summary
Note: Function 4 (F4) is for Video Processor support
(although accessed through the Core Logic PCI
configuration registers). Refer to Section 7.3.1
"Register Summary" on page 327 for details.
