Core Logic Module - ISA Legacy Register Space
Table 6-46. Programmable Interrupt Controller Registers (Continued)
Bit
Description
3
IRQ3 / IRQ11 Pending.
0: Yes.
1: No.
2
IRQ2 / IRQ10 Pending.
0: Yes.
1: No.
1
IRQ1 / IRQ9 Pending.
0: Yes.
1: No.
0
IRQ0 / IRQ8 Pending.
0: Yes.
1: No.
Interrupt Service Register
7
IRQ7 / IRQ15 In-Service.
0: No.
1: Yes.
6
IRQ6 / IRQ14 In-Service.
0: No.
1: Yes.
5
IRQ5 / IRQ13 In-Service.
0: No.
1: Yes.
4
IRQ4 / IRQ12 In-Service.
0: No.
1: Yes.
3
IRQ3 / IRQ11 In-Service.
0: No.
1: Yes.
2
IRQ2 / IRQ10 In-Service.
0: No.
1: Yes.
1
IRQ1 / IRQ9 In-Service.
0: No.
1: Yes.
0
IRQ0 / IRQ8 In-Service.
0: No.
1: Yes.
