Figure 3-19 Metal Cover in Unused Slot P1
4. Supporting the power supply with both hands, slide it into slot P1 until it plugs into the
socket on the internal power supply board. Hand tighten the thumbscrew.
5. Install the power cord into the power supply socket and secure it to the power cord bracket.
6. Apply power (200 - 240 VAC) to the new power supply. The LED immediately turns on.

Installing Hot-Pluggable Disk Drives

One additional hot-pluggable disk drive can be added to the server in slot 2. Always use low
profile disk drives (1 inch height) in the server.
To install a hot-pluggable disk drive, follow these steps:
Installing Additional Components 75
