Figure 1-10 iLO MP LAN LEDs – Example 2
Table 1-6 provides iLO MP LED status descriptions.
Table 1-6 iLO MP LED Status Descriptions – Example 2
LED
100 M green
100 M green
10 M amber
10 M amber

Single-Port Gigabit Ethernet LAN Card

The single-port Gigabit Ethernet LAN card uses an RJ-45 LAN connector. This connector has
four LEDs (three LAN link and one LAN activity) that signal link speed and activity.
Figure 1-1 1 Single-Port GigE LAN Connector and LEDs
Table 1-7 lists the single-port Gigabit Ethernet LAN card LED status descriptions.
Table 1-7 Single-Port GigE LAN LED Status Descriptions
LED
Activity
Activity
Activity
1000-BaseT
100-BaseT
10-BaseT
Figure 1-12 and
descriptions.
Condition
On
Blinking
On
Blinking
Color
Green
Green
Green
Green
Green
Green
Table 1-8 show the dual-port Gigabit Ethernet LAN card LEDs and status
Status
Linked at 100 MBs, no activity
Linked at 100 MBs, activity present
Linked at 10 MBs, no activity
Linked at 10 MBs, activity present
Condition
On
Off
Blinking
On
On
On
Status
Linked, no activity
No link
Linked, activity present
Link speed—1000 MBs
Link speed—100 MBs
Link speed—10 MBs
Controls, Ports, and LEDs 31
