NOTE: After pushing the Attention button, you have five seconds to cancel the operation
by pushing the Attention button again. After five seconds, pressing the Attention button
initiates slot power off for OLR of the card.
10. Replace the top cover. (See
11. Push the server all the way back into the rack until it stops.

OLR

CAUTION: For HP-UX 11i v1 (and higher), you must replace an existing card with an identical
card.
To remove and replace a PCI/PCI-X card into a populated slot, follow these steps:
1. If rack-mounted, slide the server out from the rack until it stops. See
from the Rack" (page
2. Remove the top cover from the chassis. See
3. Disconnect all external and internal cables attached to the PCI card in the side service bay.
4. Press the Attention button located on the OLX divider that controls the affected slot. The
power LED starts to blink. Wait until the power LED goes from blinking to steady off.
NOTE:
After pushing the Attention button, you have five seconds to cancel the operation
by pushing the Attention button again.
5. Turn the PCI/PCI-X card latch approximately 45 degrees on the chassis until the MRL is free
to pull up.
6. To turn off power to the slot, pull up on the MRL located on the OLX divider.
7. To completely expose the PCI/PCI-X bulkhead, turn the PCI/PCI-X card latch on the chassis
approximately 90 degrees.
8. If the PCI/PCI-X card is full size, open the slider gate latch to release the end of the card.
(Figure 3-35)
9. Grasp the top edge of the PCI/PCI-X card and remove it from the slot.
NOTE: There is no ejection lever to remove PCI/PCI-X cards as on previous server models.
You must remove the PCI/PCI-X card manually. Cutouts in the OLX dividers enable access
for grasping PCI/PCI-X cards.
10. Insert the new PCI/PCI-X card into the powered off slot.
IMPORTANT:
When inserting the PCI/PCI-X card, be careful you do not accidentally touch
an Attention button on the other OLX dividers. This initiates an undesired shutdown of
another PCI/PCI-X card/slot. If you accidentally initiate slot shutdown, push the Attention
button again within five seconds to cancel the shutdown.
NOTE: Ensure that you fully seat the card into the slot, or undesired results can occur after
power is reapplied to the slot.
11. If the PCI/PCI-X card is full size, close the slider gate latch to secure the end of the card.
(Figure 3-33)
12. Push the MRL down until it seats against the chassis wall.
13. Turn the PCI/PCI-X card latch on the chassis to the closed position. This locks the PCI/PCI-X
card into its slot and the MRL into the closed position.
14. Press the Attention button. The power LED starts to blink.
"Replacing the Top Cover" (page
58).
"Removing the Top Cover" (page
66).)
"Extend the Server
65).
(Figure
(Figure 3-34)
Installing Additional Components
3-33)
95
