Replacement Parts List

NOTE: If you need to replace a system board, first remove the processors, DIMMs, and adapter
boards, and then transfer them to the new board.
You must transfer all jumper and switch settings from the old board to the new board.
Use this parts list whenever ordering parts for the HP 9000 rp4410 and rp4440 servers.
Table A-2 Replacement Parts List
Manufacturing Part
Number
Cables
A6961-63006
A6961-63005
A6961-63004
A6961-63003
A6961-63011
A6961-63008
A6961-63002
A7231-63024
A7231-63025
PCA Boards
A6961-60007
A6961-60201
A6961-60204
A7124-04006
A6961-60005
A6961-04075
A6961-60106
A6961-60008
A6961-60009
A6961-60015
A6961-60113
A6967AX
A6968AX
A6969AX
232 Replacement Parts
Description
Internal SCSI, Cable
QuickFind Diagnostic to Midplane, Cable
Power Distribution to Midplane Ribbon,
Cable
Power Distribution to Midplane 10 pin,
Cable
SCSI Controller Jumper (Simplex only),
Cable
SCSI Backplane to Midplane, Cable
Display to IDE to Midplane, Cable
Single-channel Internal SCSI Cable
Dual-channel Internal SCSI Cables(2)
Processor Extender PCA
I/O Baseboard (includes VRMs) PCA
16 slot Memory Board PCA
32 slot Memory Board PCA
Midplane Riser Board PCA
SCSI Backplane/Management Assembly,
includes: Management Board
(A6961-60103) and SCSI Backplane Board
(A6961-60002) PCA
SCSI Duplex Board (HP-UX) PCA
Front Panel Display PCA
QuickFind (visual) Diagnostic Board
(includes plastic cover and label) PCA
Power Distribution Board PCA
I/O Board to DVD Connectivity (IDE/USB)
PCA
256 MB DIMM
512 MB DIMM
1 GB DIMM
Part Number Part Number
Replacement Exchange
A6961-63006 N/A
A6961-63005 N/A
A6961-63004 N/A
A6961-63003 N/A
A6961-63011 N/A
A6961-63008 N/A
A6961-63002 N/A
A7231-63024 N/A
A7231-63025 N/A
A6961-67007 A6961-69007
A6961-67401 A6961-69401
A6961-67204 A6961-69204
A9739-67007 A9739-69007
A6961-67005 N/A
A6961-67024 N/A
A6961-67106 N/A
A6961-67008 N/A
A6961-67009 N/A
A6961-67015 N/A
A6961-67113 N/A
A6967AX N/A
A6968AX N/A
A6969AX A6969-69001
Customer Self
Repair
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
AY
AY
AY
