4-6 Setting Up the Hub

Setting Attachment Port Configurations

To configure the attachment ports, use the set attach command.
1.
2.
Type the command:
set attach
This selection prompt appears:
Select one of the following:
1. B/A
2. S/M
3. M/M
Attachment port configuration?
Enter the configuration you want. For example, type:
2 [Enter]
A confirmation message similar to the following appears:
Current configuration is : B/A
Initialize attachment as : S/M
This message means that the hub's current attachment port configuration is
B/A (dual attachment). When you reset the hub, the attachment ports will
be initialized as S/M. (Refer to Chapter 3, "Configuring the Hub," for
descriptions and diagrams of the attachments supported by the LinkBuilder
FDDI Workgroup Hub.)
