Overview
By interpreting the LEDs on the management module, you can:
Refer to "Interpreting the LEDs" in Chapter 5 for detailed information about the
LEDs on all hub modules.
Media Modules
Three media modules are currently available. Each module can be placed in any
slot, but the modules must be installed from the bottom up, beginning with slot 1.
Do not leave empty slots between modules.
The two leftmost ports on any module installed in slot 1 are designated as
attachment ports. The module in slot 1 is given a default configuration of dual
attachment, B/A connection. Only the two leftmost ports of modules installed in
slot 1 can be configured.
The three modules are:
Fiber Media Port Module
The fiber media port module provides four ports, as shown in Figure 1-6. When
this module is installed in slot 1, you can configure the attachment ports (the two
leftmost ports) as B and A, S and M, or M and M as necessary to support a given
attachment. (Refer to Chapter 4 for instructions for configuring the attachment
ports.) The remaining two ports are M (master) ports by default.
Monitor network activity
Determine chassis environmental factors
Discover ring attachment configuration
LinkBuilder FDDI 4-port Optic Module (fiber media port module)
LinkBuilder FDDI 6-port STP Module (STP media port module)
LinkBuilder FDDI 8-port UTP Module (UTP media port module)
