3Com's FDDI Training and
®
Reference Manual
Understanding FDDI (3CS-360) is a pragmatic independent study course and
reference manual written for professionals involved in the design,
implementation, or support of multivendor FDDI networks.
Chapters 1 through 5 contain core information about FDDI. These chapters
explore critical elements of an FDDI environment, including attachment
stations, MAC interfaces, concentrators, and optical bypass switches. Port
keying and configuration, internetworking, ring startup, operation, fault
isolation and ring recovery, light properties, fiber media, and optics are also
covered.
Chapters 6 through 12 constitute a 250-page technical reference that takes
you down to the engineering level. Here 3Com interprets the FDDI standards
to provide tangible and accessible information on all four FDDI protocol
layers and the SMT Management Information Base.
This text-based course comes with a testing diskette to guide and reinforce
the learning process. Students who pass the test receive a certificate of
completion.
For ordering information and details about other courses in 3Com's data
networking technology series, turn the page.
GRN = SIGNAL DETECT
YEL GRN = LINK ERROR = PORT STATE
®
LinkBuilder ® 3
® PWR
FDDI WORKGROUP HUB
GRN = SIGNAL DETECT
GRN = PORT STATE
YEL = LINK ERROR
®
2
PWR
GRN = SIGNAL DETECT
GRN = PORT STATE FIBER PORT MODULE
YEL = LINK ERROR
®
1
PWR
GRN = SIGNAL DETECT MANAGEMENT MODULE
GRN = PORT STATE OPTICAL ATTACH
YEL = LINK ERROR SERIAL PORT
® BYPASS
B/A
0 FAN HI
PWR RESET STATUS TOKEN WRAP FAIL TEMP
S/M
M/M
UTP PORT MODULE
STP PORT MODULE
LOW
BATT
