Configuring the Hub
Dual Attachment Hub
A dual attachment hub (DAC) attaches to both the primary and the secondary
rings. Figure 3-1 shows a hub functioning as a dual attachment hub.
Legend
Figure 3-1. Dual Attachment Hub (DAC)
Primary ring
Secondary ring
DAC
B
A
Primary ring (trunk ring)
Secondary ring
